Figure 21: Aach the APOUTBR-ART2 Mounng Bracket 1 to a Pole
3. Aach the APOUTBR-ART2 mounng bracket 2 to the mounng bracket 1 by using two bolts and
nuts included in the bracket kit. Orient the side with the label ← UP → as shown in Figure 22 on
page 23.
Figure 22: Aach the APOUTBR-ART2 Mounng Bracket 2 to the Mounng Bracket 1
23
