Figure 30: CTP2000 Serial DCE/DTE Cable Pin Configurations
3—1— DB-25 connectorDB-25 shell
2—Thumb screw
Table 16 on page 53 lists the CTP2000 serial DCE cable pinouts.
Table 16: CTP2000 Serial DCE Cable Pinouts
DB-25J1 SCSICable
P0-21P0
P0-1451
P0-202
P0-2352
P0-43
P0-1953
P0-154
53
