Juniper CTP2000 Series Hardware Guide

Table 19: CTP2000 Series Console Cable (p/n 720-071594) Pinouts for the PP833 Processor (continued)
DB-9 MaleUSB Console Connector
5 GND4 GND
Table 20: DB9-to-RJ45 Adapter (p/n 450-071855) Pinouts for Connecting PP833 Processor with Console
DB-9RJ-45
5 GND3 TXD
3 TXD4 GND
2 RXD5 GND
Table 21: DB9-to-RJ45 Adapter (p/n 720-056657) Pinouts to Convert PP833 Console to CTP150 Console
Pinout
DB-9RJ-45
7 RTS1 RTS
4 DTR2 DTR
3 TXD3 TXD
5 GND4 GND
2 RXD6 RXD
6 DSR7 DSR
8 CTS8 CTS
Table 22: DB9-to-RJ45 Adapter (p/n 720-014126) Pinouts for Connecting PP833 Processor with a PC
DB-9RJ-45
8 CTS1 RTS
6 DSR2 DTR
2 RXD3 TXD
5 GND4 GND
65
