Page #180 background imageLoading...
Page #180 background image
vlan [ 500 600 ];
}
}
}
}
routing-instances {
vs {
instance-type virtual-switch;
interface ge-3/2/4.0;
interface ge-5/2/3.0;
bridge-domains {
bd100 {
vlan-id 100;
}
bd101 {
vlan-id 101;
}
bd200 {
vlan-id 200;
}
bd300 {
vlan-id 300;
}
bd500 {
vlan-id 500;
}
bd600 {
vlan-id 600;
}
}
}
}
}
Configuring ERP on CS2
CLI Quick
Configuration
To quickly configure CS2 for ERP, copy the following commands and paste them into
the switch terminal window of CS2:
[edit]
set interfaces ge-2/0/4 unit 0 family bridge interface-mode trunk
set interfaces ge-2/0/4 unit 0 family bridge vlan-id-list 100-1000
set interfaces ge-2/0/8 unit 0 family bridge interface-mode trunk
set interfaces ge-2/0/8 unit 0 family bridge vlan-id-list 100-1000
set protocols protection-group ethernet-ring ring-1 east-interface control-channel ge-2/0/4.0
set protocols protection-group ethernet-ring ring-1 east-interface control-channel vlan 100
set protocols protection-group ethernet-ring ring-1 west-interface control-channel ge-2/0/8.0
set protocols protection-group ethernet-ring ring-1 west-interface control-channel vlan 100
set protocols protection-group ethernet-ring ring-1 data-channel vlan [200, 300]
set protocols protection-group ethernet-ring ring-2 ring-protection-link-owner
set protocols protection-group ethernet-ring ring-2 east-interface control-channel ge-2/0/4.0
set protocols protection-group ethernet-ring ring-2 east-interface control-channel vlan 101
set protocols protection-group ethernet-ring ring-2 west-interface control-channel ge-2/0/8.0
set protocols protection-group ethernet-ring ring-2 west-interface ring-protection-link-end
set protocols protection-group ethernet-ring ring-2 west-interface control-channel vlan 101
set protocols protection-group ethernet-ring ring-2 data-channel vlan [500, 600]
set bridge-domains bd100 vlan-id 100
Copyright © 2012, Juniper Networks, Inc.160
