Juniper QFX5120 Series Hardware Guide

Cable Specifications for QSFP+ and QSFP28 Transceivers on QFX5120
Switches
The 40-Gigabit Ethernet QSFP+ and 100-Gigabit Ethernet QSFP28 transceivers that are used in QFX5120
switches use 12-ribbon multimode fiber crossover cables with female MPO/UP, MPO/UPC, or MPO/APC
connectors. The fiber can be either OM3 or OM4. These cables are not sold by Juniper Networks.
CAUTION: To maintain agency approvals, use only a properly constructed, shielded
cable.
TIP: Ensure that you order cables with the correct polarity. Vendors refer to these crossover cables
as key up to key up, latch up to latch up, Type B, or Method B. If you are using patch panels between
two QSFP+ ports, ensure that the proper polarity is maintained through the cable plant.
Table 29 on page 77 describes the signals on each fiber.
Table 29: QSFP+ and QSFP28 MPO Cable Signals
SignalFiber
Tx0 (Transmit)1
Tx1 (Transmit)2
Tx2 (Transmit)3
Tx3 (Transmit)4
Unused5
Unused6
Unused7
Unused8
Rx3 (Receive)9
Rx2 (Receive)10
77

Juniper QFX5120 Series Specifications

General

Rack Units	1 U
Junos OS	Yes
Form Factor	Fixed
Power Supply	Dual, hot-swappable
Cooling	Front-to-back or back-to-front airflow
Fans	Hot-swappable
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Humidity	5% to 90% non-condensing
AC Power Input	100 to 240 VAC
Management Ports	1x RJ-45 console, 1x USB, 1x RJ-45 management
