Juniper QFX5120 Series Hardware Guide

Parts Inventory (Packing List) for a QFX5120 Switch
The switch shipment includes a packing list. Check the parts you receive with the switch against the items
in the packing list. The packing list specifies the part number and provides a description of each part in
your order. The parts shipped depend on the switch model you order.
If any part in the packing list is missing, contact your customer service representative or contact Juniper
customer care from within the U.S. or Canada by telephone at 1-888-314-5822. For international-dial or
direct-dial options in countries without toll-free numbers, see
https://www.juniper.net/support/requesting-support.html .
Table 38 on page 92 lists the parts and their quantities as in the standard packing list for a QFX5120
switch.
Table 38: Inventory of Components Provided with an QFX5120 Switch
Quantity
Component
1Switch
5 preinstalled
6 preinstalled
QFX5120-48Y
QFX5120-32C
Fan modules
2 (AC or DC) preinstalledQFX5120Power supplies
2QFX5120AC power cord
appropriate for
your
geographical
location
•
Rear mounting blades - 2
•
Front mounting brackets - 2
•
Extension brackets -2
•
Mounting screws -12
Mounting brackets
1RJ-45 cable and RJ-45 to DB-9 serial port adapter
1Quick Start installation instructions
1Juniper Networks Product Warranty
1End User License Agreement
92

Juniper QFX5120 Series Specifications

General

Rack Units	1 U
Junos OS	Yes
Form Factor	Fixed
Power Supply	Dual, hot-swappable
Cooling	Front-to-back or back-to-front airflow
Fans	Hot-swappable
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Humidity	5% to 90% non-condensing
AC Power Input	100 to 240 VAC
Management Ports	1x RJ-45 console, 1x USB, 1x RJ-45 management
