6. Repeat Step 4 and Step 5 for the other spacer bar.
7. Tighten all the screws completely.
Installing the Small Mounting Shelf
The small shelf installs on the back of the rear rails, extending toward the center of the
rack. See Table 1 on page 7.
1. Partially insert a mounting screw into the lowest hole specified in Table 1 on page 7.
2. Install the small shelf on the back of the rear rack rails. Rest the bottom slot on each
flange on one of the mounting screws.
3. Partially insert screws into the open holes in the ears of the small shelf.
4. Tighten all the screws completely.
Removing the Center-Mounting Brackets
The router is shipped with a spacer bar attached to the back of each front-mounting
flange, and two center-mounting brackets attached to the chassis. Remove the center
mounting brackets from the chassis by loosening the screws at the top and bottom of
each bracket.
Installing the Mounting Hardware in an Open-Frame Rack
To install the mounting hardware for an open frame rack:
•
Front-mount: Attach the large mounting shelf on the back of the rails. Remove the
center-mounting brackets from the chassis.
•
Center mount: Attach the large mounting shelf on the back of the rails. You do not
have to remove the center-mounting brackets from the chassis.
The small mounting shelf is not needed for open-frame racks.Table 2 on page 10 specifies
the holes in which you insert mounting screws, and cage nuts if needed.
