Just Motion Control 2DM556 - Current Setting; Standstill Current Setting; Micro Steps Setting

Shenzhen Just Motion Control Electro-mechanics Co., Ltd 0755-26509689
- 14 -
Dial switch
Current
SW1
SW2
SW3
Peak
RMS
1.4A
1.0A
0
0
0
2.1A
1.5A
1
0
0
2.7A
1.92A
0
1
0
3.2A
2.28A
1
1
0
3.8A
2.71A
0
0
1
4.3A
3.07A
1
0
1
4.9A
3.5A
0
1
1
5.6A
4.0A
1
1
1
6.2 Standstill current Setting
SW4 is used for setting the standstill current , “off” means the
standstill current is set to be half of the selected dynamic current or other
current, which can be set by the HISU, the details can be seen in the tenth
sections. While “on” means the standstill current is set to be the same as
the selected dynamic current.
6.3 Micro steps Setting
The micro steps setting is in the following table. And the micro steps
can be also setting through the HISU. The details can be seen in the tenth
sections.
