Just Motion Control 2DM556 - Ports Introduction; ALM Signal Output Ports

Shenzhen Just Motion Control Electro-mechanics Co., Ltd 0755-26509689
- 5 -
 Support PUL/DIR and CW/CCW modes
 Storage the position of motor
 Optically isolated input and compatible with 5V or 24V
 User-defined micro steps
 Micro-step resolutions and Output current programmable
 Over current, over voltage and low voltage protection
 Green light means running while red light means protection or
off line
3. Ports Introduction
3.1 ALM signal output ports
1
2
Port
Symbol
Name
Remark
1
ALM+
Alarm output +
+
-
2
ALM-
Alarm output -
