Just Motion Control 2DM556 - Faults Alarm and LED Flicker Frequency

Shenzhen Just Motion Control Electro-mechanics Co., Ltd 0755-26509689
- 16 -
0.8s 2s
Red Alarm LED Flash Time Interval
Flicker
Frequency
Description to the Faults
1
Error occurs when the motor coil current exceeds
the drive’s current limit.
2
Voltage reference error in the drive
3
Parameters upload error in the drive
4
Error occurs when the input voltage exceeds the
drive’s voltage limit.
