11-3/8"(287mm)
13-5/8" (346mm)
Front 13"(327.5mm)
Rear 11-1/8"(280mm)
13-1/8"(332mm)
7-5/8"(193mm)
*
*
8-5/8"(217mm)
DIMENSIONS
E. & O.E. Design and specifications subject to change without notice.
BM-H1300SU
The faceplate dimensions shown are larger than the visible portion of screen (Screen size).
BM-H1900SU
The faceplate dimensions shown are larger than the visible portion of screen (Screen size).
16-1/4" (410mm)
9-3/8"(238mm)
3-5/8"
(91.5mm)
1/4"(5mm)
1/8"(2mm)
17-3/4" (449mm)
14-5/8"(370mm)
17"(431mm)
9-1/2"(240mm)
*
11-3/4"(298mm)
VOLUME PHASE CHROMA BRIGHT CONTRAST
UNDER
SCAN
PULSE
CROSS
COLOR
OFF
BLUE
CHECK
MEMORY
MODE
RGB/
COMPO(SDI)
EXT
SYNC
A B
Y/C
VIDEO
MENU DEG AUSS
ENTER
INPUT SELECT
POWER
ON
OFF
15-7/8"(401mm)
*
20-1/8" (511mm)
13-7/8"(351mm)
3-5/8"
(91.5mm)
1/2"(11mm)
3/8"(7mm)
