SPECIFICATIONS
Type : Color video monitor
Color systems : NTSC 3.58 MHz, NTSC
4.43MHz,PAL
Picture tube : [BM-H1900SU]
19" (47.5 cm) diagonally measured,
90° deflection, in-line gun, medium-
high-definition cathode-ray tube, trio-
dot type (dot pitch of 0.4 mm),
SMPTE-C phosphor
[BM-H1300SU]
13" (33 cm) diagonally measured,
90°deflection, in-line gun,
high-definition tinted cathode ray
tube, trio-dot type (dot pitch of 0.28
mm), SMPTE-C phosphor
Screen size (WxH) : [BM-H1900SU]
15-11/16" x 11-3/4" (399mm x 298mm)
[BM-H1300SU]
11-1/16" x 8-5/16" (280mm x 210mm)
Scanning frequency : H: 15.734 kHz (NTSC 3.58/4.43 MHz)
15.625 kHz (PAL)
V: 59.94 Hz (NTSC 3.58/4.43MHz)
50 Hz (PAL)
Horizontal resolution : 750 TV lines or more
Color temperature : 6500K; x = 0.313, y = 0.329
9300K; x = 0.283, y = 0.297
(selectable)
Video inputs : Composite video
INPUT A, B (2 lines), BNC x 2 each
(with 1 bridge-connected output)
Termination switches provided
1.0 V p-p, 75 , negative sync
: Y/C
Y/C (1 line), Mini-DIN (4-pin) x 2
(with 1 bridge-connected output)
Termination switch provided
Y: 1.0 V p-p, 75 , negative sync
C (NTSC 3.58/4.43 MHz):
0.286 Vp-p, 75
C (PAL): 0.3 V p-p, 75
: Analog RGB
RGB/COMPO(SDI)
(1 line: common with Y, R-Y, B-Y,
component),
BNC x 6 (with 3 bridge-connected
outputs)
Termination switches provided
R,B: 0.7 V p-p, 75
G: 0.7 V p-p, 75
G on sync: 1.0 V p-p, 75 , negative
sync
: Y, R-Y, B-Y component
RGB/COMPO(SDI)
(1 line: common with analog RGB)
Y: 1.0 V p-p, 75 , negative sync
R-Y, B-Y: 0.7 V p-p, 75
External sync inputs : SYNC (1 line),
BNC x 2 (with 1 bridge-connected
output)
0.2 – 4.0 V p-p composite sync,
75 , negative sync
Termination switch provided
Audio inputs : AUDIO A, B, RGB/COMPO(SDI)
(3 lines), RCA x 2 each
(with 1 bridge-connected output)
500 mV rms, high impedance
Tally/remote terminal : TALLY/REMOTE, DIN (8-pin) x 1
Audio power output : 1.6 W
Built-in speaker : 3-9/16" x 2" (9 x 5 cm) oval x 1
Operation temperature : 0 – 40°C (20 – 80% RH)
Power requirements : 120 V AC, 50/60 Hz
Power consumption : 0.9 A
Dimensions (WxHxD) : [BM-H1900SU]
17-3/4" x 17" x 20-1/8"
(449 mm x 431 mm x 511 mm)
[BM-H1300SU]
13-5/8" x 13-1/8" x 16-1/4"
(346 mm x 332 mm x 410 mm)
Weight : [BM-H1900SU] 66 lbs (30 kg)
[BM-H1300SU] 35.6 lbs (16.2 kg)
Provided accessory : Power cord x 1
Optional accessories : Wireless remote control unit
(RM-C550W)
