JVC BM-H1900SU - Color Production Monitor - Product Features; Key Monitor Capabilities

3
ENGLISH
Thank you for purchasing this JVC color video monitor.Before using it, read and follow all
instructions carefully to take fullest advantage of the monitor's performance.
SAFETY PRECAUTIONS ----------------------------------- 2
FEATURES ------------------------------------------------------ 3
CONTROLS AND FEATURES (FRONT) --------------- 4
TERMINALS AND FEATURES (REAR) ---------------- 5
CONNECTION EXAMPLE ---------------------------------- 6
External/internal synchronization------------------------- 6
RGB/COMPO(SDI) terminal setting --------------------- 6
BASIC OPERATION ------------------------------------------ 7
To demagnetize the picture tube ------------------------- 7
PICTURE ADJUSTMENTS --------------------------------- 8
CONTRAST (picture contrast) ---------------------------- 8
BRIGHT (picture brightness) ------------------------------ 8
CHROMA (picture color density) ------------------------- 8
PHASE (picture hue) ---------------------------------------- 8
Relation between picture adjustments and input video signals--- 8
VIDEO SIGNAL CONTROLS------------------------------- 9
UNDER SCAN------------------------------------------------- 9
PULSE CROSS ----------------------------------------------- 9
COLOR OFF --------------------------------------------------- 9
BLUE CHECK ------------------------------------------------- 9
ON-SCREEN MENU CONTROLS ---------------------- 10
Calling up the menu display, selecting an item----- 10
ASPECT RATIO (picture aspect ratio switching) -- 10
FILTER SELECT (built-in filter selection) ------------ 10
PEAKING FREQ./PEAKING LEVEL (picture quality improvement) ------ 11
AFC (switching of time constant for the AFC) ------ 11
COLOR TEMP. (color temperature switching) ----- 11
NTSC SETUP (NTSC set-up level)-------------------- 11
COMPO. LEVEL (chrominance level setting)------- 11
MEMORY MODE--------------------------------------------- 12
Recall/release of memory mode------------------------ 12
Setting programming of the picture being monitored----- 12
Revision of memory mode ------------------------------- 12
SET-UP FOR MONITOR INSTALLATION------------ 14
To call up SET-UP MENU and select a function--- 14
SIZE/CENTERING (size/positioning adjustments of RGB signal pictures) -- 14
WHITE BALANCE ADJUST (white balance adjustments) -- 15
REMOTE SELECT (TALLY/REMOTE-terminal settings)---- 15
STATUS DISPLAY (setting the status display to on/off)-- 16
CONTROL LOCK (deactivation of front-control functions) -- 16
PICTURE SETTING INITIALIZATION ---------------- 17
To initialize MENU settings only------------------------ 17
To initialize both MENU/SET-UP MENU settings-- 17
REMOTE CONTROLS ------------------------------------- 18
On-screen menu remote operation -------------------- 18
Picture adjustments ---------------------------------------- 18
Sound adjustments----------------------------------------- 18
EACH REMOTE CONTROL OF PLURAL MONITORS -- 19
To program an ID number-------------------------------- 19
To call up an ID number ---------------------------------- 19
To assign a monitor ---------------------------------------- 19
BEFORE CALLING FOR SERVICE -------------------- 20
MENU DISPLAY CHART ---------------------------------- 21
SPECIFICATIONS ------------------------------------------- 22
CONTENTS
FEATURES
■ For multiple applications with various video systems; equipped with external source
component terminals that can be bridge-connected.
■ Compatible with NTSC-3.58/4.43 MHz or PAL color systems.
■ The BM-H1900SU has a medium-high-definition picture tube that reproduces pictures
with a horizontal resolution of 750 TV lines or more .
The BM-H1300SU has a high-definition picture tube that reproduces pictures with a
horizontal resolution of 750 TV lines or more .
■ Auto white-balance stabilizer (I/K feedback circuit) maintains stable color reproduction
over long-term use.
■ A range of flexible functions includes picture aspect ratio switching (between 4:3 and
16:9), memory mode and control lock.
■ Optional exclusive wireless remote control unit enables individual operation and adjust-
ment of up to 99-unit monitors.
