CH-X400/CH-X450
3-7
Item
Parts number Parts name Area
Electrical parts list (Main board)
Remarks
Block No. 01
Item
Parts number Parts name Area
Remarks
C 101 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 102 NCB31HK-821X C CAPACITOR
C 103 NCS31HJ-121X C CAPACITOR
C 104 QERF0JM-476Z E CAPACITOR 47MF 20% 6.3V
C 105 NBE21AM-106X E CAPACITOR
C 106 NCS31HJ-101X C CAPACITOR
C 111 NCS31HJ-101X C CAPACITOR
C 112 NCB31HK-103X C CAPACITOR
C 201 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 202 NCB31HK-821X C CAPACITOR
C 203 NCS31HJ-121X C CAPACITOR
C 204 QERF0JM-476Z E CAPACITOR 47MF 20% 6.3V
C 205 NBE21AM-106X E CAPACITOR
C 206 NCS31HJ-101X C CAPACITOR
C 501 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 502 NCB31HK-103X C CAPACITOR
C 503 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 504 NCB31HK-103X C CAPACITOR
C 505 NCB31HK-103X C CAPACITOR
C 506 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 507 NCB31HK-103X C CAPACITOR
C 508 NCB31CK-104X C CAPACITOR
C 509 NCB31CK-104X C CAPACITOR
C 510 NDC31HJ-680X C CAPACITOR
C 512 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 513 NCB31HK-103X C CAPACITOR
C 514 NCS31HJ-101X C CAPACITOR
C 522 NCB31HK-103X C CAPACITOR
C 523 NBE21CM-105X C CAPACITOR
C 524 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 525 NCB31HK-103X C CAPACITOR
C 526 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 533 NCS31HJ-470X C CAPACITOR
C 534 NCB31HK-153X C CAPACITOR
C 536 NCB31HK-103X C CAPACITOR
C 537 NCB31HK-272X C CAPACITOR
C 538 NCB31HK-103X C CAPACITOR
C 539 NCB31EK-333X C CAPACITOR
C 542 NCB31HK-182X C CAPACITOR
C 543 NCS31HJ-271X C CAPACITOR
C 544 QERF0JM-476Z E CAPACITOR 47MF 20% 6.3V
C 545 NCB31EK-473X C CAPACITOR
C 546 NCB31EK-473X C CAPACITOR
C 547 NCB31EK-473X C CAPACITOR
C 549 NCB31EK-473X C CAPACITOR
C 551 QERF0JM-476Z E CAPACITOR 47MF 20% 6.3V
C 552 NCB31HK-103X C CAPACITOR
C 553 NCB31HK-103X C CAPACITOR
C 554 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 555 NCB31HK-103X C CAPACITOR
C 556 NDC31HG-100X C CAPACITOR
C 557 NDC31HG-100X C CAPACITOR
C 558 NCS31HJ-101X C CAPACITOR
C 571 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 573 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 574 NCB31HK-103X C CAPACITOR
C 581 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 582 NCB31HK-103X C CAPACITOR
C 583 QERF1CM-226Z E CAPACITOR 22MF 20% 16V
C 601 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 602 NCB31HK-103X C CAPACITOR
C 603 NCS31HJ-220X C CAPACITOR
C 604 NCS31HJ-220X C CAPACITOR
C 605 QERF0JM-476Z E CAPACITOR 47MF 20% 6.3V
C 606 NCB31HK-103X C CAPACITOR
C 609 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 610 NCB31CK-104X C CAPACITOR
C 611 NCB31CK-104X C CAPACITOR
C 612 NCB31CK-104X C CAPACITOR
C 651 NCB31HK-103X C CAPACITOR
C 901 QEZ0338-228 E CAPACITOR 2200MF
C 902 NCB31HK-103X C CAPACITOR
C 906 NCS31HJ-101X C CAPACITOR
C 907 NCS31HJ-101X C CAPACITOR
C 912 QERF1CM-107Z E CAPACITOR 100MF 20% 16V
C 913 QERF1AM-107Z E CAPACITOR 100MF 20% 10V
C 914 NCB31HK-103X C CAPACITOR
C 915 NCB31HK-103X C CAPACITOR
C 941 QERF1AM-107Z E CAPACITOR 100MF 20% 10V
C 942 NCB31HK-103X C CAPACITOR
C 943 QERF1CM-476Z E CAPACITOR 47MF 20% 16V
C 944 NCB31HK-103X C CAPACITOR
C 945 NCB31HK-103X C CAPACITOR
C 946 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 951 NCB31HK-103X C CAPACITOR
C 982 NCB31HK-103X C CAPACITOR
C 983 QERF1CM-476Z E CAPACITOR 47MF 20% 16V
CN501 QGF1014F1-15 FPC CONNECTOR
CN502 QGF1029F1-26 CONNECTOR
CN503 QGF1009F2-26 FFC/FPC CONECTOR
CN504 QGA2501F1-02 CONNECTOR
CN601 QGA2501F1-03 CONNECTOR
CN902 QNZ0095-001 CONNECTOR
CN903 QGF1004F4-10 CONNECTOR
CN904 QGF1009F2-10 CONNECTOR
D 101 HSM2836C-W DIODE
D 583 DSK10C-T1 DIODE
D 584 DSK10C-T1 DIODE
D 585 DSK10C-T1 DIODE
D 911 DSK10C-T1 DIODE
D 912 MA3062/H/-X ZENER DIODE
D 913 HSM2836C-W DIODE
D 921 HSM2838C-W DIODE
D 941 MA3100/L/-X ZENER DIODE
D 951 MA3051/M/-X ZENER DIODE
D 981 MA3091/M/-X ZENER DIODE
F 901 ICP-N70 IC PROTECTER
IC101 BA15218F-XE IC
IC501 TA2109F-X IC
IC521 TC9462F IC
IC581 BA5926S IC
IC601 UPD780058GC-067 IC
IC602 IC-PST600M/G/-W IC
IC604 BR24C01AF-X IC
IC651 HD74HC126FP-X IC
L 521 QQL231K-4R7Y INDUCTOR
L 551 QQL231K-4R7Y INDUCTOR
L 601 QQL231K-4R7Y INDUCTOR
101 2SD1048/6-7/-X TRANSISTOR
201 2SD1048/6-7/-X TRANSISTOR
501 2SB1322/RS/-T TRANSISTOR
581 2SB1322/RS/-T TRANSISTOR
602 2SC2412K/R/-X TRANSISTOR
901 2SA1037AK/R/-X TRANSISTOR
902 DTC114EKA-X TRANSISTOR
911 2SD1994A/RS/-T TRANSISTOR
