CH-X400/CH-X450
3-8
Item
Parts number Parts name Area
Electrical parts list (Main board)
Remarks
Block No. 01
Item
Parts number Parts name Area
Remarks
Q
921 2SC2412K/R/-X TRANSISTOR
Q
922 2SA1037AK/R/-X TRANSISTOR
Q
941 2SB941A/QP/ TRANSISTOR
Q
942 2SD1994A/RS/-T TRANSISTOR
Q
943 DTA114EKA-X TRANSISTOR
Q
944 DTC114EKA-X TRANSISTOR
Q
971 2SA1037AK/R/-X TRANSISTOR
Q
972 2SC2412K/R/-X TRANSISTOR
Q
981 2SD1994A/RS/-T TRANSISTOR
R 101 NRSA63J-273X MG RESISTOR
R 102 NRSA63J-123X MG RESISTOR
R 103 NRSA63J-333X MG RESISTOR
R 104 NRSA63J-223X MG RESISTOR
R 105 NRSA63J-223X MG RESISTOR
R 106 NRSA63J-103X MG RESISTOR
R 107 NRSA63J-471X MG RESISTOR
R 108 NRSA63J-682X MG RESISTOR
R 112 NRSA63J-470X MG RESISTOR
R 201 NRS181J-273X MG RESISTOR
R 202 NRSA63J-123X MG RESISTOR
R 203 NRSA63J-333X MG RESISTOR
R 204 NRSA63J-223X MG RESISTOR
R 205 NRSA63J-223X MG RESISTOR
R 206 NRSA63J-103X MG RESISTOR
R 207 NRSA63J-471X MG RESISTOR
R 208 NRSA63J-682X MG RESISTOR
R 501 NRSA63J-473X MG RESISTOR
R 502 NRSA63J-473X MG RESISTOR
R 503 NRS181J-104X MG RESISTOR
R 504 NRSA63J-473X MG RESISTOR
R 505 NRSA63J-473X MG RESISTOR
R 506 NRSA63J-104X MG RESISTOR
R 507 NRSA63J-220X MG RESISTOR
R 508 NRSA63J-220X MG RESISTOR
R 509 NRSA63J-273X MG RESISTOR
R 510 NRSA63J-393X MG RESISTOR
R 511 NRSA63J-222X MG RESISTOR
R 512 NRSA63J-153X MG RESISTOR
R 513 NRSA63J-682X MG RESISTOR
R 514 NRSA63J-473X MG RESISTOR
R 521 NRSA63J-472X MG RESISTOR
R 522 NRSA63J-472X MG RESISTOR
R 523 NRSA63J-472X MG RESISTOR
R 524 NRSA63J-472X MG RESISTOR
R 525 NRSA63J-103X MG RESISTOR
R 531 NRSA63J-103X MG RESISTOR
R 532 NRSA63J-473X MG RESISTOR
R 533 NRSA63J-683X MG RESISTOR
R 534 NRSA63J-474X MG RESISTOR
R 536 NRSA63J-333X MG RESISTOR
R 537 NRSA63J-103X MG RESISTOR
R 541 NRSA63J-122X MG RESISTOR
R 542 NRSA63J-103X MG RESISTOR
R 543 NRSA63J-332X MG RESISTOR
R 544 NRSA63J-332X MG RESISTOR
R 545 NRSA63J-332X MG RESISTOR
R 547 NRSA63J-332X MG RESISTOR
R 571 NRSA63J-101X MG RESISTOR
R 581 NRS181J-332X MG RESISTOR
R 582 NRSA63J-123X MG RESISTOR
R 583 NRSA63J-102X MG RESISTOR
R 584 NRS181J-102X MG RESISTOR
R 601 NRSA63J-472X MG RESISTOR
R 602 NRS181J-103X MG RESISTOR
R 603 NRSA63J-472X MG RESISTOR
R 604 NRSA63J-472X MG RESISTOR
R 605 NRSA63J-472X MG RESISTOR
R 606 NRSA63J-103X MG RESISTOR
R 607 NRSA63J-103X MG RESISTOR
R 609 NRSA63J-473X MG RESISTOR
R 610 NRSA63J-473X MG RESISTOR
R 611 NRSA63J-473X MG RESISTOR
R 612 NRSA63J-473X MG RESISTOR
R 614 NRSA63J-473X MG RESISTOR
R 617 NRSA63J-473X MG RESISTOR
R 618 NRSA63J-102X MG RESISTOR
R 619 NRSA63J-103X MG RESISTOR
R 620 NRSA63J-104X MG RESISTOR
R 621 NRSA63J-473X MG RESISTOR
R 622 NRSA63J-103X MG RESISTOR
R 625 NRSA63J-472X MG RESISTOR
R 626 NRSA63J-473X MG RESISTOR
R 651 NRSA63J-223X MG RESISTOR
R 652 NRSA63J-101X MG RESISTOR
R 653 NRSA63J-223X MG RESISTOR
R 654 NRSA63J-334X MG RESISTOR
R 655 NRSA63J-101X MG RESISTOR
R 656 NRSA63J-223X MG RESISTOR
R 657 NRSA63J-334X MG RESISTOR
R 658 NRSA63J-331X MG RESISTOR
R 659 NRSA63J-104X MG RESISTOR
R 660 NRSA63J-103X MG RESISTOR
R 661 NRSA63J-104X MG RESISTOR
R 901 NRSA63J-103X MG RESISTOR
R 902 NRSA63J-392X MG RESISTOR
R 903 NRSA02J-222X MG RESISTOR
R 911 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R 912 QRE141J-2R2Y C RESISTOR 2.2 5% 1/4W
R 921 NRSA63J-273X MG RESISTOR
R 923 NRSA63J-184X MG RESISTOR
R 924 NRSA63J-682X MG RESISTOR
R 925 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 926 NRSA63J-223X MG RESISTOR
R 941 NRS181J-100X MG RESISTOR
R 942 NRSA63J-471X MG RESISTOR
R 943 NRSA63J-332X MG RESISTOR
R 951 NRSA63J-122X MG RESISTOR
R 954 NRSA63J-272X MG RESISTOR
R 971 NRSA63J-223X MG RESISTOR
R 972 NRSA63J-222X MG RESISTOR
R 973 NRSA63J-104X MG RESISTOR
R 981 NRSA63J-221X MG RESISTOR
R 982 NRSA63J-221X MG RESISTOR
S 601 VSH1173-001 SWITCH
S 602 VSH1173-001 SWITCH
S 603 VSH1173-001 SWITCH
S 604 VSH1173-001 SWITCH
S 606 QSW0643-001Z TACT SWITCH
X 521 QAX0413-001Z CRYSTAL
X 601 QAX0414-001Z CRYSTAL
