JVC CL-S500 Series User Manual

- 8 -
Guidance and manufacturer’s declaration – electromagnetic immunity
The model CL-S500 is intended for use in the electromagnetic immunity environment (Home
healthcare environment dened in IEC 60601-1-2) specied below.
The customer or the user of the model CL-S500 should assure that it is used in such an
environment.
Immunity test IEC 60601 test level Compliance level
Electromagnetic
environment
–guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
±8 kV contact
±15 kV air
±8 kV contact
±15 kV air
Floors should be wood,
concrete or ceramic
tile. If oors are
covered with synthetic
material, the relative
humidity should be at
least 30 %.
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV for power
supply lines 100 kHz
±1 kV for input/output
lines 100 kHz
±2 kV for power
supply lines 100 kHz
Mains power quality
should be that of a
typical commercial or
hospital environment.
Surge
IEC 61000-4-5
±1 kV line(s) to line(s)
±2 kV line(s) to earth
±1 kV line(s) to line(s)
±2 kV line(s) to earth
Mains power quality
should be that of a
typical commercial or
hospital environment.
Voltage dips, short
interruptions and
voltage variations on
power supply input
lines
IEC 61000-4-11
0 %
U
T
(100 % dip in
U
T
)
0.5 cycles and
1 cycle
70 %
U
T
(30 % dip in
U
T
)
25/30 cycles
0 %
U
T
(100 % dip in
U
T
)
250/300 cycles
0 %
U
T
(100 % dip in
U
T
)
0.5 cycles and
1 cycle
70 %
U
T
(30 % dip in
U
T
)
25/30 cycles
0 %
U
T
(100 % dip in
U
T
)
250/300 cycles
Mains power quality
should be that of a
typical commercial or
hospital environment.
If the user of the model
CL-S500 requires
continued operation
during power mains
interruptions, it is
recommended that the
model CL-S500 be
powered from an
uninterruptible power
supply or a battery.
Power
frequency (50/60 Hz)
magnetic eld
IEC 61000-4-8
30 A/m
50 Hz or 60 Hz
30 A/m
50 Hz or 60 Hz
Power frequency
magnetic elds should
be at levels
characteristic of a
typical location in a
typical commercial or
hospital environment.
The product should be
kept at least 15 cm
away from the source
of power frequency
magnetic elds during
use.
Note:
U
T
is the a.c. mains voltage prior to application of the test level.
