JVC DDX5707S User Manual

Appendix
68
■ DSP section
Graphics equalizer
Band: 13 Band
Frequency (BAND1 – 13)
: 62.5/ 100/ 160/ 250/ 400/ 630/ 1k/ 1.6k/ 2.5k/ 4k/
6.3k/ 10k/ 16k Hz
Gain
: -9/ -8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0/
+1/ +2/ +3/ +4/ +5/ +6/ +7/ +8/ +9 dB
2Way X'Over
High pass lter
Frequency: Through, 30/ 40/ 50/ 60/ 70/ 80/ 90/
100/ 120/ 150/ 180/ 220/ 250 Hz
Slope: -6/ -12/ -18/ -24 dB/ Oct.
Gain: -8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0 dB
Low pass lter
Frequency: 30/ 40/ 50/ 60/ 70/ 80/ 90/ 100/ 120/
150/ 180/ 220/ 250 Hz, Through
Slope: -6/ -12/ -18/ -24 dB/ Oct.
Gain: -8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0 dB
Position
Front / Rear /Subwoofer Delay
: 0 – 20.01 ft (0.03 or 0.04 ft Step)
Gain
: -8 – 0 dB
Subwoofer level
: -40 – +6 dB
■ FM tuner section
Frequency Range (step)
: 87.9 MHz – 107.9 MHz (200 kHz)
Usable Sensitivity (S/N: 30 dB)
: 16.2 dBf (1.8 μV/75 Ω)
Quieting Sensitivity (DIN S/N : 46 dB)
: 13 dBf (4.47 μV/75 Ω)
Frequency Response (± 3.0 dB)
: 30 Hz – 14 kHz
S/N (dB)
: 50 dB (MONO)
Selectivity (± 400 kHz)
: Over 80 dB
Stereo Separation
: 35 dB (1 kHz)
■ AM tuner section
Frequency Range (step)
: 530 – 1700 kHz (10 kHz)
Usable Sensitivity
: 99 μV (40 dBμ)
■ Video section
Color System of External Video Input
: NTSC/ PAL
External Video Input Level (Mini jack)
: 1 Vp-p/ 75 Ω
External Audio Max Input Level (RCA jack)
: 1.5 V/ 25 kΩ
Video Output Level (RCA jacks)
: 1 Vp-p/ 75 Ω
■ Audio section
Maximum Power Output (Front & Rear)
: 45 W × 4
Full Bandwidth Power (at less than 1% THD)
: 21 W × 4
Output Frequency Band
: 20 – 20,000 Hz
Preout Level (V)
: 2 V/ 10 kΩ
Preout Impedance
: 1.4 kΩ
Speaker Impedance
: 4 – 8 Ω
■ General
Operating Voltage
: 12V DC Car Battery
Installation Dimensions (W × H × D)
: 182 × 112 × 153 mm
7-3/16 × 4-7/16 × 6 inch
Main Unit Installation size (W × H × D)
: 178 × 100 × 153 mm (w/o sleeve)
7 × 3-15/16 × 6 inch
Weight
: 2.0 kg (4.4 lbs)
(Including Sleeve and Trim plate)
NOTE
• Although the effective pixels for the liquid
crystal panel is given as 99.99% or more, 0.01% of
pixels may not light or may light incorrectly.
Specications subject to change without
notice.
