1-2 (No.PA045<Rev.001>)
SPECIFICATION
GENERAL
OPTICAL
ELECTRIC
INPUT CONNECTORS
OUTPUT CONNECTORS
CONTROL CONNECTORS
Design and specifications are subject to change without notice.
Type D-ILA PROJECTOR
Power requirements AC 110 to 240 V 50 Hz / 60 Hz
Power Consumption 330 W (Standby mode: 0.4 W) [X35/XC3800]
360 W (Standby mode: 0.4 W) [X55R/XC5800R/X75R/XC7800R/X95R/XC9800R]
Operating temperature +5°C to +35°C
Operating humidity 20%~80% (no-condensation)
Storage temperature -10°C to +60°C
Installation Height Below 5000 ft (1524 m)
Dimensions (W × H ×D) About. 455 mm × 179 mm × 472 mm
Mass 14.8 kg [X35/XC3800]
15.1 kg [X55R/XC5800R]
15.4 kg [X75R/XC7800R/X95R/XC9800R]
Remote control unit operation Distance: 7m / Angle: Horizontal =±30° Vertical =±20°
Accessories Remote control unit (RM-MH15G) × 1 [X35/XC3800]
Remote control unit (RM-MH17G) × 1 [X55R/XC5800R]
Remote control unit (RM-MH18G) × 1 [X75R/XC7800R/X95R/XC9800R]
Dry cell battery (size : UM-4/AAA/R02) × 2
Power code (2m) × 1 (CHINA/US model)
Power code (2m) × 2 (Europe model)
Projection system D-ILA(reflective activematrix principle)system
D-ILA device 0.7-inch(1.7 cm) measured diagonally [H: 1920 pixels × V: 1080 pixels] × 3 <Total: 6,220,000 pixels>
Projection lens 2.0x power zoom lens (1.4 : 1 to 2.8 : 1) (Zoom / Focus: Power)
Screen size Approx. 60" to 200" (Aspect ratio : 16 : 9)
Projection distance Approx. 1.8 m to 12 m
Lamp unit UHP (Ultra High-Pressure mercury) lamp
Color system NTSC, NTSC4.43, PAL, PAL-M, PAL-N, SECAM (Auto/Manual switch)
Analog video input format 480i, 480p, 576i, 576p, 720p/50 Hz, 720p/60 Hz, 1080i/50 Hz, 1080i/60 Hz
Digital video input format 480i, 480p, 576i, 576p, 720p/50 Hz, 720p/60 Hz, 1080i/50 Hz, 1080i/60 Hz, 1080p/24 Hz, 1080p/50
Hz, 1080p/60 Hz
PC input format [X75R/
XC7800R/X95R/XC9800R]
VGA60, VGA59.94, SVGA60, XGA60, WXGA60, WXGA+60, SXGA60, WSXGA+60, WUXGA60
Resolution 1920 dots x 1080 dots [X35/XC3800]
3840 dots x 2160 dots [X55R/XC5800R/X75R/XC7800R/X95R/XC9800R]
HDMI Input 2 system, HDMI 19 pin x 2 (HDCP compliant) Compatible with the HDMIv1.4a standard
Component Video Input 1 system, RCA pin jack x 3
Y: 1.0 V(p-p), 75 Ω
Pb/Cb, Pr/Cr: 0.7 V(p-p), 75 Ω
PC Input [X75R/XC7800R/
X95R/XC9800R]
1 system, D-Sub 15 pin x 1
Trigger terminal 1 system, Ø 3.5 mm DC Power Jack, DC OUT 12V/0.1A
3D synchro 3D synchro emitter dedicated terminal (1 system, mini DIN 3 pin)
RS-232C 1 system, D-sub 9-pin (Male) x 1 (External control)
Remote terminal 1 system, stereo mini jack x 1 (Remote control)
LAN terminal 1 system, RJ-45 Plug x 1
To Next Page
