MODEL MARK MODEL MARK MODEL MARK MODEL MARK
DLA-X35BE A DLA-X35BU B DLA-X35WE C DLA-X35WU D
DLA-X55RBE E DLA-X55RBU F DLA-X55RWE G DLA-X75RBE H
DLA-X75RBU I DLA-X95RBE J DLA-X95RBU K DLA-XC3800B L
DLA-XC5800RB M DLA-XC5800RW N DLA-XC7800RB O DLA-XC9800RB P
Safe Symbol No. Parts No. Parts Name Description QTY Local
EXPLODED VIEW <M1MM>
WR1 EWI1030009 WIRE CW PWB CN2001 or CN1001 -
PROCESSOR PWB SC_CN3
1 E,F,G,H,I,J,K,M,N,O,
P
WR2 EWI1033009 WIRE MD PWB CN2701-
PROCESSOR PWB SC_CN3
1 A,B,C,D,L
WR2 EWI4140009 WIRE MD PWB CN2701- CW PWB
CN2003
1 E,F,G,H,I,J,K,M,N,O,
P
WR3 EWI1032009 WIRE MD PWB CN2702-
PROCESSOR PWB SC_CN2
1
WR4 EWI4142009 WIRE POWER PWB CN200 -
PROCESSOR PWB SC_CN1
1 A,B,C,D,L
WR4 EWI4130009 WIRE POWER PWB CN200 -
PROCESSOR PWB
SC_CN1/CW PWB CN2004
1 E,F,G,H,I,J,K,M,N,O,
P
WR5 EWI1003009 WIRE POWER PWB EARTH (The
mounting screws) - AC
CONNECTOR
1
WR6 EWI1004009 WIRE POWER PWB CN102 -
BALLAST PWB CN1
1
WR7 EWI1005009 WIRE POWER PWB CN103 -
THERMO
1
WR8 EWI1010009 WIRE PROCESSOR PWB SC_CN6 -
KEYPAD PWB KS_CN1
1
WR9 EWI1011009 WIRE IR PWB IS_CN1 1
WR10 EWI1012009 WIRE PROCESSOR PWB SC_CN09 -
MOTOR PWB MT_CN1
1
WR11 EWI1013009 WIRE PROCESSOR PWB SC_CN10 -
MOTOR PWB MT_CN2
1
WR14 EWI1020009 WIRE MOTOR PWB MT_CN7 - LENS
BARRIER
1 H,I,J,K,O,P
WR15 EWI1021009 WIRE LAMPCOVER PWB CN - DD
SUB PWB CN5005
1
WR16 EWI1041009 WIRE DD SUB PWB CN5001 -
PROCESSOR PWB
SC_CN5/SC_CN4
1
WR17 EWI1024009 WIRE TEMP SENSOR PWB CN1 - DD
SUB PWB CN5002
1
WR18 EWI1027009 WIRE BALLAST PWB CN3 - LAMP
UNIT
1
WR19 EWI1029009 WIRE PROCESSOR PWB SC_CN11 -
SOLENOID PWB
1 H,I,J,K,O,P
WR20 EWI1034009 WIRE PROCESSOR PWB SC_CN17 -
IRIS2 HOME SENSOR
1 H,I,J,K,O,P
WR23 EWI4129009 WIRE DD PWB CN1004 - MD PWB
CN2704
1
WR24 EWI4128009 WIRE DD PWB CN1003 - MD PWB
CN2703
1
WR25 EWI4127009 WIRE DD SUB PWB CN5008 - MD
PWB CN5001
1
WR26 EWI1039009 WIRE POWER PWB CN101 - AC
CONNECTOR
1
WR27 EWI4143009 WIRE POWER PWB CN201 - DD SUB
PWB CN6001
1 A,B,C,D,L
WR27 EWI4132009 WIRE POWER PWB CN201 - MD2
PWB CN8001/MD PWB
CN8001/DD SUB PWB CN6001
1 E,F,G,H,I,J,K,M,N,O,
P
WR28 EWI1022009 WIRE DD SUB PWB CN5006 -
/BALLAST PWB CN2
1
WR29 EWI1042009 WIRE PROCESSOR PWB
SC_CN14/SC_CN15/SC_CN16/
- TERMINAL-1 PWB
T1_CN1/T1_CN2/TERMINAL-2
PWB T2-CN2
1
WR30 EWI1043009 WIRE DD PWB CN6001 - DD SUB
PWB CN6002
1 A,B,C,D,L
WR30 EWI4144009 WIRE DD PWB CN6001 - DD SUB
PWB CN6002
1 E,F,G,H,I,J,K,M,N,O,
P
WR31 EWI1044009 WIRE DD PWB CN1005 - DD SUB
PWB CN5003
1
WR32 EWI1045009 WIRE PROCESSOR PWB SC_CN13 -
TERMINAL-2 PWB T2-CN1
1 H,I,J,K,O,P
WR33 EWI4125009 WIRE DD SUB PWB CN5007 -
THERMISTER
1
WR36 EWI4137009 WIRE MD2 PWB CN2703 - DD PWB
CN1001
1 E,F,G,H,I,J,K,M,N,O,
P
WR37 EWI4138009 WIRE MD2 PWB CN2704 - DD PWB
CN1002
1 E,F,G,H,I,J,K,M,N,O,
P
WR39 EWI4136009 WIRE DD SUB PWB CN5012 - MD2
PWB CN5001
1 E,F,G,H,I,J,K,M,N,O,
P
WR40 EWI4139009 WIRE MD2 PWB CN2701 - CW PWB
CN2002
1 E,F,G,H,I,J,K,M,N,O,
P
S1 PC010666399 SCREW 22
S2 PB006564599 SCREW 1
S3 PC010666299 SCREW 3
(No.PA045<Rev.001>)4/
