JVC DLA-X35BE - SECTION 2 SPECIFIC SERVICE INSTRUCTIONS; 2.1 DIFFERENCE POINT; 2.2 SUPPORT THE REPAIR OF EACH PCB;BLOCK

(No.PA045<Rev.001>)1-7
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
2.1 DIFFERENCE POINT
2.2 SUPPORT THE REPAIR OF EACH PCB/BLOCK
Item
DLA-X35B
DLA-XC3800B
DLA-X35W
DLA-X55RB
DLA-XC5800RB
DLA-X75RB
DLA-XC7800RB
DLA-X95RB
DLA-XC9800RB
Cabinet color Black White Black ←←
Remote Controller RM-MH15G ← RM-MH17G RM-MH18G ←
PC terminal No ←←Yes ←
Lens shutter No ←←Yes ←
Contrast 50,000:1 ←←90,000:1 130,000:1
Picture mode 6 mode (Preset)
5 mode (Custam)
←←7+4 mode (Preset)
5 mode (Custam)
←
Item
Part No.
Method for repair
DLA-X35B
DLA-X35W
DLA-XC3800B
DLA-X55RB
DLA-XC5800RB
DLA-X75RB
DLA-XC7800RB
DLA-X95RB
DLA-XC9800RB
PROCESSOR PWB PC0234152U9 PC0234153U9 PC0234154U9 ← PWB exchange
MOTOR PWB PC0210613U9 ← PC0106805U9 ← PWB exchange
TERMINAL-1 PWB PC0210612U9 ←←←PWB exchange
TERMINAL-2 PWB PC0106807U9 ← PC0106808U9 ← PWB exchange
LED&IR PWB PC0106809U9 ←←←PWB exchange
KEYPAD PWB PC0106810U9 ←←←PWB exchange
LAMPCOVER PWB PC0106811U9 ←←←PWB exchange
TEMP SENSOR PWB PC0106817U9 ←←←PWB exchange
POWER PWB PC0210605U9 ←←←PWB exchange
BALLAST PWB PC023411199 ←←←PWB exchange
DD PWB NAL0111-001 NAL0111-002 ←←PWB exchange
DD SUB PWB NAL0107-002 ←←←PWB exchange
MD PWB NAL0097-003 ←←←PWB exchange
MD2 PWB - NAL0097-004 ←←PWB exchange
CW PWB - NAL0117-001 ←←PWB exchange
OPTICAL BLOCK
(Include the following PWB)
• DD SUB PWB
• CW PWB [Except X35,XC3800]
PC0234884U9 PC0234885U9 PC0234886U9 PC0234887U9 OPTICAL BLOCK
exchange
DD FAN PC021061499 ←←←
EXHAUST FAN PC010665499 ←←←
DEVICE COOLING FAN PC010665399 ←←←
INTAKE FAN PC010665499 ←←←
EXHAUST DUCT FAN PC010665499 ←←←
LAMP COOLING FAN PC023410999 ←←←
PCS COOLING FAN - PB006533599 ←←
FILTER PC010661199 ←←←
