MODEL MARK MODEL MARK MODEL MARK MODEL MARK
DLA-X35BE A DLA-X35BU B DLA-X35WE C DLA-X35WU D
DLA-X55RBE E DLA-X55RBU F DLA-X55RWE G DLA-X75RBE H
DLA-X75RBU I DLA-X95RBE J DLA-X95RBU K DLA-XC3800B L
DLA-XC5800RB M DLA-XC5800RW N DLA-XC7800RB O DLA-XC9800RB P
Safe Symbol No. Parts No. Parts Name Description QTY Local
S4 PB006571299 HDMI SCREW 2
S5 PC010666799 TAPPING SCREW 22
S7 PC010666599 TAPPING SCREW 4
S8 PC010666799 TAPPING SCREW 1 A,B,C,D,E,F,G,L,M,N
S8 PC010666799 TAPPING SCREW 6 H,I,J,K,O,P
! 1 PC010660099 BOTTOM CABINET 1
! 2 PC021060099 TOP CABINET 1 A,B,E,F,L,M
! 2 PC021060199 TOP CABINET 1 C,D,G,N
! 2 PC010664299 TOP CABINET 1 H,I,J,K,O,P
! 5 PC021060499 FRONT PANEL 1 A,B,E,F,L,M
! 5 PC010672799 FRONT PANEL 1 C,D,G,N
! 5 PC010660499 FRONT PANEL 1 H,I,J,K,O,P
! 7 PC010660599 REAR PANEL 1
! 8 PC010668999 SIDE PANEL 2 A,B,E,F,L,M
! 8 PC010673699 SIDE PANEL 2 C,D,G,N
! 8 PC010660799 SIDE PANEL 2 H,I,J,K,O,P
9 PC010639699 BLIND SW HOLE 1
10 PC010660899 LAMP DOOR 1
11 PC010660999 CONTROL BUTTON 1
12 PC010661099 FOOT 4
13 PC007270299 FOOT RUBBER 4
14 PC010661199 FILTER 1
15 PC010661299 LENS LED 1
16 PC010661399 BOTTOM CHASSIS 1
17 PC021064499 SHIELD CENTER 1
18 PC021064699 SHIELD POWER 1
19 PC021064599 SHIELD RIGHT 1
20 PC010661799 SHIELD LEFT 1
21 PC010661899 SHIELD MAIN 1
22 PC021060799 SHIELD REAR 1
23 PC010662099 SHIELD TOP 1
24 PC010662199 LENS RING 1 A,B,E,F,H,I,J,K
24 PC010669099 LENS RING 1 C,D,G,L,M,N,O,P
25 PC010665499 EXHAUST FAN 1
26 PC010665399 DEVICE COOLING FAN 1
27 PC010662399 PUNCHING METAL 2
28 PC010662399 PUNCHING METAL 2 A,B,E,F,H,I,J,K,L,M,
O,P
28 PC010668399 PUNCHING METAL 2 C,D,G,N
29 PC010665499 INTAKE FAN 1
30 PC010665499 EXHAUST DUCT FAN 1
31 PC010663099 CONNECTOR BRACKET 1
32 PC023414699 EXHAUST DUCT BOTTO 1
M
33 PC023414799 EXHAUST DUCT TOP 1
34 PC023414899 EXHAUST DUCT COVER 1
35 PC010667399 HOLE COVER 1 A,B,C,D,E,F,G,L,M,N
36 PC010663899 BLIND EXHAUST 1
37 PC010663999 BLIND INTAKE 1
39 PK-L2312UG LAMP UNIT 1 A,B,C,D,E,F,G,H,I,J,
K
39 PK-L2312UC LAMP UNIT 1 L,M,N,O,P
! 40 ECN4555009 AC CONNECTOR 1
41 PC023410999 LAMP COOLING FAN 1
42 PB006533599 PCS COOLING FAN 1 H,I,J,K,O,P
43 PC0234156U9 LENS COVER ASSY 1 A,B,C,D,E,F,G,L,M,N
43 PC0234155U9 LENS COVER ASSY 1 H,I,J,K,O,P
44 PC0234884U9 OPTICAL BLOCK 1 A,B,C,D,L
44 PC0234885U9 OPTICAL BLOCK 1 E,F,G,M,N
44 PC0234886U9 OPTICAL BLOCK 1 H,I,O
44 PC0234887U9 OPTICAL BLOCK 1 J,K,P
45 PC010662799 FAN SPRING 6
46 PC010634899 FAN RUBBER 12
47 PC010662599 FAN BRACKET 2 1
48 PC021062199 FAN BRACKET 3 1
49 PC010662499 FAN BRACKET 1 1
50 PC023410399 DUCT BALLAST 1
51 PC023410799 LAMP FAN BRACKET 1
52 PC023410899 LAMP FAN SPRING 1
53 PC010663199 OE HOLDER 1
54 PC010663299 OE COVER 1
55 PC010663699 IRIS DUCT 1 H,I,J,K,O,P
56 PC010664599 IRIS DUCT COVER 1 H,I,J,K,O,P
57 PC010639899 TERMINAL PLATE 1 A,B,C,D,E,F,G,L,M,N
60 PB006560599 FRONT IR COVER 2
61 PC010635199 BLIND SHEET 1
62 PC010668599 SPONGE 1
63 PC010668499 SPONGE 2
64 PC023411099 SPONGE 2
65 PC021060999 DUMPER 2
66 PC010668299 SPONGE 1
67 PB006579099 BLOWER RUBBER 6
68 PC010665599 SPONGE 1 H,I,J,K,O,P
69 PC010664099 DUMPER 2 H,I,J,K,O,P
70 PC010635299 HEAT SINK 1
71 PC021010299 DD SHIELD TOP 1
72 PC021010199 DD SHIELD BOTTOM 1
73 PC021010499 COOLING SHEET 3
74 PC021063299 HEAT SINK 1 A,B,C,D,L
74 PC021063299 HEAT SINK 2 E,F,G,H,I,J,K,M,N,O,
(No.PA045<Rev.001>)5/
