JVC DLA-X35BE - Page 35

MODEL MARK MODEL MARK MODEL MARK MODEL MARK
DLA-X35BE A DLA-X35BU B DLA-X35WE C DLA-X35WU D
DLA-X55RBE E DLA-X55RBU F DLA-X55RWE G DLA-X75RBE H
DLA-X75RBU I DLA-X95RBE J DLA-X95RBU K DLA-XC3800B L
DLA-XC5800RB M DLA-XC5800RW N DLA-XC7800RB O DLA-XC9800RB P
Safe Symbol No. Parts No. Parts Name Description QTY Local
P
75 PC021063199 SHIELD MD 2
76 PC021062999 BRACKET 1
77 PC021062899 BRACKET 1
78 PC010639599 COOLING SHEET 1 A,B,C,D,L
78 PC010639599 COOLING SHEET 2 E,F,G,H,I,J,K,M,N,O,
P
80 PB006580999 E SHEET 1
81 PC021063799 CENTER BRACKET 1
82 PC021060999 DUMPER 4
83 PC021061099 SPONGE 1
84 PC021061499 DD FAN 1
85 PC021061199 DD FAN DUCT 1
86 PC021061299 SPONGE 2
87 PC021061399 SPONGE 2
88 PC023410199 SHIELD CW 1 E,F,G,H,I,J,K,M,N,O,
P
89 PC010639599 COOLING SHEET 1 E,F,G,H,I,J,K,M,N,O,
P
90 PC021060599 LENS CAP 1 A,B,C,D,E,F,G,L,M,N
91 PC023415099 PC SHEET 1
92 PC023410299 HEAT SINK 1 E,F,G,H,I,J,K,M,N,O,
P
93 PC023413699 SPONGE 1
! PW1 PC0234152U9 PROCESSOR PWB 1 A,B,C,D,L
! PW1 PC0234153U9 PROCESSOR PWB 1 E,F,G,M,N
! PW1 PC0234154U9 PROCESSOR PWB 1 H,I,J,K,O,P
! PW2 PC0210613U9 MOTOR PWB 1 A,B,C,D,E,F,G,L,M,N
! PW2 PC0106805U9 MOTOR PWB 1 H,I,J,K,O,P
! PW3 PC0210612U9 TERMINAL-1 PWB 1
! PW4 PC0106807U9 TERMINAL-2 PWB 1 A,B,C,D,E,F,G,L,M,N
! PW4 PC0106808U9 TERMINAL-2 PWB 1 H,I,J,K,O,P
! PW5 PC0106809U9 IR PWB 1
! PW6 PC0106810U9 KEYPAD PWB 1
! PW7 PC0106811U9 LAMPCOVER PWB 1
! PW8 PC0106817U9 TEMP SENSOR PWB 1
! PW9 PC0210605U9 POWER PWB 1
! PW10 PC023411199 BALLAST PWB 1
! PW11 NAL0111-001 DD PWB 1 A,B,C,D,L
! PW11 NAL0111-002 DD PWB 1 E,F,G,H,I,J,K,M,N,O,
P
! PW13 NAL0097-003 MD PWB 1
! PW15 NAL0117-001 CW PWB 1 E,F,G,H,I,J,K,M,N,O,
P
! PW16 NAL0097-004 MD2 PWB 1 E,F,G,H,I,J,K,M,N,O,
P
(No.PA045<Rev.001>)6/
8
