JVC DLA-X9BE - About the Connection; Types of Possible Input Signals (PC Compatible)

24
Preparation
2
About the connection
Types of possible input signals (PC compatible)
●
HDMI
No.
Designation
Resolution
fh
[kHz]
fv
[Hz]
dot CLK
[MHz]
Total No.
of dots
[dot]
Total No.
of lines
[line]
No. of
effective
dots
[dot]
No. of
effective
lines [line]
1
VGA
60 640 X 480 31.500 60.000 25.200 800 525 640 480
2
VGA
59.94 640 X 480 31.469 59.940 25.175 800 525 640 480
3
SVGA
60 800 X 600 37.879 60.317 40.000 1,056 628 800 600
4
XGA
60 1024 X 768 48.363 60.004 65.000 1,344 806 1,024 768
5
WXGA
60 1280 X 768 47.760 60.000 79.998 1,675 796 1,280 768
6
WXGA
+60 1440 X 900 55.919 59.999 106.470 1,904 932 1,440 900
7
SXGA
60 1280 X 1024 63.981 60.020 108.000 1,688 1,066 1,280 1,024
8
WSXGA
+60 1680 X 1050 65.222 60.002 147.140 2,256 1,087 1,680 1,050
9
WUXGA
60 1920 X 1200 74.038 59.95 154.000 2,080 1,235 1,920 1,200
●
PC (D-sub 3-lines 15 pins)
No.
Designation
Resolution
fh
[kHz]
fv
[Hz]
dot CLK
[MHz]
Total No.
of dots
[dot]
Total
No. of
lines
[line]
No. of
effective
dots
[dot]
No. of
effective
lines [line]
1
VGA
60 640 X 480 31.500 60.000 25.175 800 525 640 480
2
VGA
72 640 X 480 37.900 72.000 31.500 832 520 640 480
3
VGA
75 640 X 480 37.500 75.000 31.500 840 500 640 480
4
VGA
85 640 X 480 43.300 85.000 36.000 832 509 640 480
5
SVGA
56 800 X 600 35.200 56.000 36.000 1024 625 800 600
6
SVGA
60 800 X 600 37.900 60.000 40.000 1056 628 800 600
7
SVGA
72 800 X 600 48.100 72.000 50.000 1040 666 800 600
8
SVGA
75 800 X 600 46.900 75.000 49.500 1056 625 800 600
9
SVGA
85 800 X 600 53.700 85.000 56.250 1048 631 800 600
10
XGA
60 1024 X 768 48.400 60.000 65.000 1344 806 1024 768
11
XGA
70 1024 X 768 56.500 70.000 75.000 1328 806 1024 768
12
XGA
75 1024 X 768 60.000 75.000 75.750 1312 800 1024 768
13
XGA
85 1024 X 768 68.700 85.000 94.500 1376 808 1024 768
14
WXGA
60 1280 X 768 47.760 60.000 79.998 1675 796 1280 768
15
WXGA+
60 1440 X 900 55.919 59.999 106.470 1904 932 1440 900
16
SXGA
60 1280 X 1024 64.000 60.000 108.000 1688 1066 1280 1024
17
SXGA+
60 1400 X 1050 63.981 60.020 108.000 1688 1066 1400 1050
18
WSXGA+
60 1680 X 1050 65.222
60.002 147.140 2256 1087 1680 1050
19 1920x1080 60 1920 X 1080 67.500 60.00 148.500 2200 1
125 1920 1080
20
MAC
13" 640 X 480 35.000 66.667 30.240 864 525 640 480
21
MAC
16" 832 X 624 49.107 75.087 55.000 1120 654 832 624
22
MAC
19" 1024 X 768 60.241 74.927 80.000 1328 804 1024 768
