JVC DT-V1710CG Service Manual

1-22 (No. 52152)
S[D04] PHASE -064 ~ +063 000
S[D05] APERTURE -064 ~ +063 000
S[D06] BRIGHT LOW -128 ~ +127 000
S[D07] Y DL 000/001 000 (Fixed value)
S[D08] R-Y PHASE 000 ~ 003 000 (Fixed value)
S[D09] R/B GAIN 000 ~ 003 002 (Fixed value)
S[D10] G-Y PHASE 000 ~ 003 002 (Fixed value)
S[D11] G/B GAIN 000 ~ 003 003 (Fixed value)
SE [COMP. 480/60i]
S[E01] CONTRAST -064 ~ +063 +018
S[E02] BRIGHT HIGH -128 ~ +127 000
S[E03] CHROMA -064 ~ +063 000
S[E04] PHASE -064 ~ +063 000
S[E05] APERTURE -064 ~ +063 000
S[E06] BRIGHT LOW -128 ~ +127 000
S[E07] Y DL 000/001 000 (Fixed value)
S[E08] R-Y PHASE 000 ~ 003 000 (Fixed value)
S[E09] R/B GAIN 000 ~ 003 002 (Fixed value)
S[E10] G-Y PHASE 000 ~ 003 002 (Fixed value)
S[E11] G/B GAIN 000 ~ 003 003 (Fixed value)
SF [COMP. 576/50i]
S[F01] CONTRAST -064 ~ +063 +018
S[F02] BRIGHT HIGH -128 ~ +127 000
S[F03] CHROMA -064 ~ +063 000
S[F04] PHASE -064 ~ +063 000
S[F05] APERTURE -064 ~ +063 000
S[F06] BRIGHT LOW -128 ~ +127 000
S[F07] Y DL 000/001 000 (Fixed value)
S[F08] R-Y PHASE 000 ~ 003 000 (Fixed value)
S[F09] R/B GAIN 000 ~ 003 002 (Fixed value)
S[F10] G-Y PHASE 000 ~ 003 002 (Fixed value)
S[F11] G/B GAIN 000 ~ 003 003 (Fixed value)
SG [COMP. 480/60p]
S[G01] CONTRAST -064 ~ +063 +018
S[G02] BRIGHT HIGH -128 ~ +127 000
S[G03] CHROMA -064 ~ +063 000
S[G04] PHASE -064 ~ +063 000
S[G05] APERTURE -064 ~ +063 000
S[G06] BRIGHT LOW -128 ~ +127 000
S[G07] Y DL 000/001 000 (Fixed value)
S[G08] R-Y PHASE 000 ~ 003 000 (Fixed value)
S[G09] R/B GAIN 000 ~ 003 002 (Fixed value)
S[G10] G-Y PHASE 000 ~ 003 002 (Fixed value)
S[G11] G/B GAIN 000 ~ 003 003 (Fixed value)
No.
