JVC DT-V1710CG Service Manual

(No. 52152) 1-23
SH [COMP. 576/50p]
S[H01] CONTRAST -064 ~ +063 +018
S[H02] BRIGHT HIGH -128 ~ +127 000
S[H03] CHROMA -064 ~ +063 000
S[H04] PHASE -064 ~ +063 000
S[H05] APERTURE -064 ~ +063 000
S[H06] BRIGHT LOW -128 ~ +127 000
S[H07] Y DL 000/001 000 (Fixed value)
S[H08] R-Y PHASE 000 ~ 003 000 (Fixed value)
S[H09] R/B GAIN 000 ~ 003 002 (Fixed value)
S[H10] G-Y PHASE 000 ~ 003 002 (Fixed value)
S[H11] G/B GAIN 000 ~ 003 003 (Fixed value)
SI [COMP. 1080/60i]
S[I01] CONTRAST -064 ~ +063 000
S[I02] BRIGHT HIGH -128 ~ +127 000
S[I03] CHROMA -064 ~ +063 000
S[I04] PHASE -064 ~ +063 000
S[I05] APERTURE -064 ~ +063 000
S[I06] BRIGHT LOW -128 ~ +127 000
S[I07] Y DL 000/001 000 (Fixed value)
S[I08] R-Y PHASE 000 ~ 003 000 (Fixed value)
S[I09] R/B GAIN 000 ~ 003 003 (Fixed value)
S[I10] G-Y PHASE 000 ~ 003 002 (Fixed value)
S[I11] G/B GAIN 000 ~ 003 000 (Fixed value)
SJ [COMP. 1035/60i]
S[J01] CONTRAST -064 ~ +063 000
S[J02] BRIGHT HIGH -128 ~ +127 000
S[J03] CHROMA -064 ~ +063 000
S[J04] PHASE -064 ~ +063 000
S[J05] APERTURE -064 ~ +063 000
S[J06] BRIGHT LOW -128 ~ +127 000
S[J07] Y DL 000/001 000 (Fixed value)
S[J08] R-Y PHASE 000 ~ 003 000 (Fixed value)
S[J09] R/B GAIN 000 ~ 003 003 (Fixed value)
S[J10] G-Y PHASE 000 ~ 003 002 (Fixed value)
S[J11] G/B GAIN 000 ~ 003 000 (Fixed value)
SK [COMP. 1080/50i]
S[K01] CONTRAST -064 ~ +063 +006
S[K02] BRIGHT HIGH -128 ~ +127 000
S[K03] CHROMA -064 ~ +063 000
S[K04] PHASE -064 ~ +063 000
S[K05] APERTURE -064 ~ +063 000
S[K06] BRIGHT LOW -128 ~ +127 000
No.
Setting item Variable range
Initial setting value
