(No. 52152) 1-39
D[T07] CORNER DISTORTION (S) -032 ~ +032 000
D[T08] PARALLELOGRAM DISTORTION -032 ~ +032 000
D[T09] TRAPEZOIDAL DISTORTION -032 ~ +032 000
D[T10] HORIZONTAL ARC DISTORTION -032 ~ +032 000
D[T11] VERTICAL LINEARITY (S CORRECTION) -016 ~ +016 000
D[T12] VERTICAL LINEARITY (C CORRECTION) -016 ~ +016 000
DU [720/60p OVER]
D[U01] HORIZONTAL SIZE -064 ~ +064 +014
D[U02] VERTICAL SIZE -064 ~ +064 +012
D[U03] HORIZONTAL POSITION -064 ~ +064 +013
D[U04] VERTICAL POSITION -064 ~ +064 000
D[U05] SIDE PIN DISTORTION -032 ~ +032 +012
D[U06] CORNER DISTORTION (W) -032 ~ +032 -002
D[U07] CORNER DISTORTION (S) -032 ~ +032 -002
D[U08] PARALLELOGRAM DISTORTION -032 ~ +032 000
D[U09] TRAPEZOIDAL DISTORTION -032 ~ +032 +001
D[U10] HORIZONTAL ARC DISTORTION -032 ~ +032 000
D[U11] VERTICAL LINEARITY (S CORRECTION) -016 ~ +016 -002
D[U12] VERTICAL LINEARITY (C CORRECTION) -016 ~ +016 000
DV [720/60p UNDER]
D[V01] HORIZONTAL SIZE -064 ~ +064 -017
D[V02] VERTICAL SIZE -064 ~ +064 -028
D[V03] HORIZONTAL POSITION -064 ~ +064 000
D[V04] VERTICAL POSITION -064 ~ +064 +001
D[V05] SIDE PIN DISTORTION -032 ~ +032 +001
D[V06] CORNER DISTORTION (W) -032 ~ +032 000
D[V07] CORNER DISTORTION (S) -032 ~ +032 000
D[V08] PARALLELOGRAM DISTORTION -032 ~ +032 000
D[V09] TRAPEZOIDAL DISTORTION -032 ~ +032 000
D[V10] HORIZONTAL ARC DISTORTION -032 ~ +032 000
D[V11] VERTICAL LINEARITY (S CORRECTION) -016 ~ +016 000
D[V12] VERTICAL LINEARITY (C CORRECTION) -016 ~ +016 000
DW [720/50p OVER]
D[W01] HORIZONTAL SIZE -064 ~ +064 +020
D[W02] VERTICAL SIZE -064 ~ +064 -010
D[W03] HORIZONTAL POSITION -064 ~ +064 000
D[W04] VERTICAL POSITION -064 ~ +064 +003
D[W05] SIDE PIN DISTORTION -032 ~ +032 +010
D[W06] CORNER DISTORTION (W) -032 ~ +032 -002
D[W07] CORNER DISTORTION (S) -032 ~ +032 -002
D[W08] PARALLELOGRAM DISTORTION -032 ~ +032 +003
D[W09] TRAPEZOIDAL DISTORTION -032 ~ +032 000
Setting item Variable range
Initial setting value
No.
