JVC DT-V1710CG Service Manual

1-40 (No. 52152)
D[W10] HORIZONTAL ARC DISTORTION -032 ~ +032 000
D[W11] VERTICAL LINEARITY (S CORRECTION) -016 ~ +016 -002
D[W12] VERTICAL LINEARITY (C CORRECTION) -016 ~ +016 -003
DX [720/50p UNDER]
D[X01] HORIZONTAL SIZE -064 ~ +064 -015
D[X02] VERTICAL SIZE -064 ~ +064 -027
D[X03] HORIZONTAL POSITION -064 ~ +064 000
D[X04] VERTICAL POSITION -064 ~ +064 000
D[X05] SIDE PIN DISTORTION -032 ~ +032 000
D[X06] CORNER DISTORTION (W) -032 ~ +032 000
D[X07] CORNER DISTORTION (S) -032 ~ +032 000
D[X08] PARALLELOGRAM DISTORTION -032 ~ +032 000
D[X09] TRAPEZOIDAL DISTORTION -032 ~ +032 000
D[X10] HORIZONTAL ARC DISTORTION -032 ~ +032 000
D[X11] VERTICAL LINEARITY (S CORRECTION) -016 ~ +016 000
D[X12] VERTICAL LINEARITY (C CORRECTION) -016 ~ +016 000
DY [ASPECT]
D[Y01] NTSC OVERSCAN VERTICAL SIZE -064 ~ +064 +008
D[Y02] NTSC OVERSCAN VERTICAL POSITION -064 ~ +064 +001
D[Y03] NTSC OVERSCAN SIDE PIN DISTORTION -032 ~ +032 +012
D[Y04] NTSC UNDERSCAN VERTICAL SIZE -064 ~ +064 +006
D[Y05] NTSC UNDERSCAN VERTICAL POSITION -064 ~ +064 +001
D[Y06] NTSC UNDERSCAN SIDE PIN DISTORTION -032 ~ +032 +012
D[Y07] PAL OVERSCAN VERTICAL SIZE -064 ~ +064 +005
D[Y08] PAL OVERSCAN VERTICAL POSITION -064 ~ +064 +001
D[Y09] PAL OVERSCAN SIDE PIN DISTORTION -032 ~ +032 +012
D[Y10] PAL UNDERSCAN VERTICAL SIZE -064 ~ +064 +005
D[Y11] PAL UNDERSCAN VERTICAL POSITION -064 ~ +064 +001
D[Y12] PAL UNDERSCAN SIDE PIN DISTORTION -032 ~ +032 +012
D[Y13] 480i OVERSCAN VERTICAL SIZE -064 ~ +064 +010
D[Y14] 480i OVERSCAN VERTICAL POSITION -064 ~ +064 +001
D[Y15] 480i OVERSCAN SIDE PIN DISTORTION -032 ~ +032 +012
D[Y16] 480i UNDERSCAN VERTICAL SIZE -064 ~ +064 +006
D[Y17] 480i UNDERSCAN VERTICAL POSITION -064 ~ +064 +001
D[Y18] 480i UNDERSCAN SIDE PIN DISTORTION -032 ~ +032 +012
D[Y19] 576i OVERSCAN VERTICAL SIZE -064 ~ +064 +010
D[Y20] 576i OVERSCAN VERTICAL POSITION -064 ~ +064 +001
D[Y21] 576i OVERSCAN SIDE PIN DISTORTION -032 ~ +032 +012
D[Y22] 576i UNDERSCAN VERTICAL SIZE -064 ~ +064 +006
D[Y23] 576i UNDERSCAN VERTICAL POSITION -064 ~ +064 +001
D[Y24] 576i UNDERSCAN SIDE PIN DISTORTION -032 ~ +032 +012
D[Y25] 480p OVERSCAN VERTICAL SIZE -064 ~ +064 +010
Setting item Variable range
Initial setting value
No.
