JVC DT-V1710CG Service Manual

(No. 52152) 1-41
D[Y26] 480p OVERSCAN VERTICAL POSITION -064 ~ +064 +001
D[Y27] 480p OVERSCAN SIDE PIN DISTORTION -032 ~ +032 +012
D[Y28] 480p UNDERSCAN VERTICAL SIZE -064 ~ +064 +006
D[Y29] 480p UNDERSCAN VERTICAL POSITION -064 ~ +064 +001
D[Y30] 480p UNDERSCAN SIDE PIN DISTORTION -032 ~ +032 +012
D[Y31] 576p OVERSCAN VERTICAL SIZE -064 ~ +064 +010
D[Y32] 576p OVERSCAN VERTICAL POSITION -064 ~ +064 +001
D[Y33] 576p OVERSCAN SIDE PIN DISTORTION -032 ~ +032 +012
D[Y34] 576p UNDERSCAN VERTICAL SIZE -064 ~ +064 +006
D[Y35] 576p UNDERSCAN VERTICAL POSITION -064 ~ +064 +001
D[Y36] 576p UNDERSCAN SIDE PIN DISTORTION -032 ~ +032 +012
DZ [V.LIN/FOCUS]
D[Z01] 45 ~ 55Hz VERTICAL LINEARITY (S CORRECTION) -016 ~ +016 +011
D[Z02] 45 ~ 55Hz VERTICAL LINEARITY (C CORRECTION) -016 ~ +016 +003
D[Z03] 45 ~ 55Hz FOCUS (PARABOLA) -032 ~ +032 000
D[Z04] 55 ~ 65Hz VERTICAL LINEARITY (S CORRECTION) -016 ~ +016 +011
D[Z05] 55 ~ 65Hz VERTICAL LINEARITY (C CORRECTION) -016 ~ +016 +003
D[Z06] 55 ~ 65Hz FOCUS (PARABOLA) -032 ~ +032 000
D[Z07] 720/60p VERTICAL LINEARITY (S CORRECTION) -016 ~ +016 000
D[Z08] 720/60p VERTICAL LINEARITY (C CORRECTION) -016 ~ +016 000
D[Z09] 720/60p FOCUS (PARABOLA) -032 ~ +032 -030
D1 [ROTATION/PURITY]
D[101] ROTATION -032 ~ +031 +017
D[102] PURITY -128 ~ +127 000
D2 [COMMON]
D[201] HORIZONTAL SIZE 000 ~ 127 063
D[202] VERTICAL SIZE 000 ~ 127 063
D[203] HORIZONTAL POSITION 000 ~ 127 063
D[204] VERTICAL POSITION 000 ~ 127 063
D[205] SIDE PIN DISTORTION 000 ~ 063 031
D[206] CORNER DISTORTION (W) 000 ~ 063 031
D[207] CORNER DISTORTION (S) 000 ~ 063 031
D[208] PARALLELOGRAM DISTORTION 000 ~ 063 031
D[209] TRAPEZOIDAL DISTORTION 000 ~ 063 031
D[210] HORIZONTAL ARC DISTORTION 000 ~ 063 031
D[211] VERTICAL LINEARITY (S CORRECTION) 000 ~ 031 016
D[212] VERTICAL LINEARITY (C CORRECTION) 000 ~ 031 016
D[213] VERTICAL MAX SIZE CONTROL 000 ~ 031 016
D[214] FOCUS (PHASE) 000 ~ 063 022
D[215] FOCUS (PARABOLA) 000 ~ 063 044
D3 [ZOOM SIZE]
D[301] HORIZONTAL SIZE -064 ~ +064 +020
Setting item Variable range
Initial setting value
No.
