1-42 (No. 52152)
D[302] VERTICAL SIZE -064 ~ +064 +040
D[303] HORIZONTAL POSITION -064 ~ +064 000
D[304] VERTICAL POSITION -064 ~ +064 000
D[305] SIDE PIN DISTORTION -032 ~ +032 -003
[CPU BLOCK]
CC [SETTING]
C[C41] AKB SETTING 000 ~ 003 000
CE [OSD etc]
C[E05] NTSC, 480/60i CORNER DISTORTION (W) -032 ~ +032 000
C[E06] NTSC, 480/60i CORNER DISTORTION (S) -032 ~ +032 000
C[E07] NTSC, 480/60i PARALLELOGRAM DISTORTION -032 ~ +032 000
C[E08] NTSC, 480/60i TRAPEZOIDAL DISTORTION -032 ~ +032 -002
C[E09] NTSC, 480/60i HORIZONTAL ARC DISTORTION -032 ~ +032 000
C[E10] PAL, 576/50i CORNER DISTORTION (W) -032 ~ +032 000
C[E11] PAL, 576/50i CORNER DISTORTION (S) -032 ~ +032 000
C[E12] PAL, 576/50i PARALLELOGRAM DISTORTION -032 ~ +032 000
C[E13] PAL, 576/50i TRAPEZOIDAL DISTORTION -032 ~ +032 -002
C[E14] PAL, 576/50i HORIZONTAL ARC DISTORTION -032 ~ +032 000
C[E15] 480/60p CORNER DISTORTION (W) -032 ~ +032 000
C[E16] 480/60p CORNER DISTORTION (S) -032 ~ +032 000
C[E17] 480/60p PARALLELOGRAM DISTORTION -032 ~ +032 000
C[E18] 480/60p TRAPEZOIDAL DISTORTION -032 ~ +032 -002
C[E19] 480/60p HORIZONTAL ARC DISTORTION -032 ~ +032 000
C[E20] 576/50p CORNER DISTORTION (W) -032 ~ +032 000
C[E21] 576/50p CORNER DISTORTION (S) -032 ~ +032 000
C[E22] 576/50p PARALLELOGRAM DISTORTION -032 ~ +032 000
C[E23] 576/50p TRAPEZOIDAL DISTORTION -032 ~ +032 -002
C[E24] 576/50p HORIZONTAL ARC DISTORTION -032 ~ +032 000
NOTE : Do not alter the adjustment values of CPU BLOCK (excluding the CC41 and CE05 to CE24), UPC1884 ADJ. and
TA1276 ADJ.
No.
Setting item Variable range
Initial setting value
No. Setting item Variable range
Initial setting value
To Next Page
