EN63
Controls
1 Diopter Adjustment Control ................ Z pg. 14
2 Lens Cover Open/Close Ring............... Z pg. 16
3 Video Light Switch
[LIGHT OFF/AUTO/ON]..................... Z pg. 19
4 Snapshot Button [SNAPSHOT] ............ Z pg. 22
5 Power Zoom Lever [T/W] .................... Z pg. 18
6 Picture Stabilizer Button
[P. STABILIZER] ................................... Z pg. 18
7 Fast-Forward Button [
3
, FF] .............. Z pg. 38
8 Rewind Button [
2
, REW] .................. Z pg. 38
9 Stop Button [5, STOP] ........................ Z pg. 38
0 Play/Pause Button
[
4
/6, PLAY/PAUSE]............................ Z pg. 38
! Select Dial [+, –, PUSH] ............... Z pg. 11, 24
@ MENU/DISPLAY Button ................ Z pg. 17, 24
# Recording Start/Stop Button ................. Z pg. 16
$ Power Switch ............................... Z pg. 16, 38
% Battery Release Switch
[BATTERY RELEASE] ........................... Z pg. 8
^ OPEN/EJECT Switch ............................ Z pg. 12
Connectors
& DC IN Jack ......................................... Z pg. 9
The connectors * to e are located beneath the
cover.
* Video Output Connector ..................... Z pg. 42
( Audio Output Connector [L] ............... Z pg. 42
) Audio Output Connector [R] ............... Z pg. 42
q External Stereo Microphone Input Connector
[MIC]
If an optional microphone is connected, the built-
in microphone is disabled.
w S-Video Output Connector [S OUT] .... Z pg. 42
e J Terminal [JLIP (Joint Level Interface Protocol)
Connector] ......................................... Z pg. 51
•Connect the editing cable when performing
Random Assemble Editing (Z pg. 50 – 55).
•It is used to connect the camcorder to a device
such as a personal computer.
For further details consult your nearest JVC
dealer.
•JLIP-controlled editing from camcorder to VCR
is not possible if the VCR is not equipped with a
J terminal.
Indicators
r Tally Lamp .......................................... Z pg. 16
t Power Lamp ....................................... Z pg. 16
Other Parts
y Battery Pack Mount ............................ Z pg. 8
u Viewfinder .......................................... Z pg. 14
i Grip Strap ........................................... Z pg. 14
o •Camera sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
•Remote Sensor ................................. Z pg. 45
p Video Light ......................................... Z pg. 19
Q Stereo Microphone
For use when recording.
W Eyepiece ............................................. Z pg. 61
E Shoulder Strap Eyelets ......................... Z pg. 15
R Clock Battery Slot ............................... Z pg. 10
T Tripod Mounting Socket ...................... Z pg. 15
