JVC GR-DVA1 - Specifications

EN69
Camcorder
General
Power supply : DC 6.0 V
Power consumption
Light on : Approx. 8.0 W
Light off : Approx. 5.0 W
Format : DV Format (SD mode)
Signal format : NTSC Standard
Video signal recording format : Digital Component Recording
Cassette : Mini DV Cassette
Tape speed : SP: 18.8 mm/s
LP: 12.5 mm/s
Maximum recording time : SP: 60 min.
LP: 90 min. (using M-DV60ME cassette)
Pickup : 1/4" CCD
Lens : F1.6, f = 3.9 to 62.4 mm, 16:1 Power Zoom Lens
Filter diameter : ø40.5 mm
Viewfinder : Electronic viewfinder with 0.55" color LCD
Operating temperature : 0°C to 40°C (32°F to 104°F)
Operating humidity : 35% to 80%
Storage temperature : –20°C to 50°C (–4°F to 122°F)
Dimensions : 89 (W) x 119 (H) x 198 (D) mm (3-7/8" x 4-11/16" x 7-13/16")
(with the viewfinder fully tilted downward)
Weight : Approx. 640 g (1.4 lbs)
Connectors
S-Video : Y: 1Vp-p, 75 Ω, analog output
C: 0.29 Vp-p, 75 Ω, analog output
JLIP : ø3.5 mm, 4-pole, mini-head jack (compatible with RC-5325 plug)
Video : 1 Vp-p, 75 Ω unbalanced, analog output (via Video output connector)
Audio : –8 dBs, 1 kΩ analog output (via Audio output connector)
External microphone input : –68 dBs, high impedance unbalanced with ø3.5 mm (stereo)
AC Power Adapter/Charger AA-V15U
Power requirement
U.S.A. and Canada : AC 120 V`, 60 Hz
Other countries : AC 110 V to 240 V`, 50/60 Hz
Power consumption : 23 W
Output
Charge : DC 8.5 V , 1.3 A
VTR : DC 6.3 V , 1.8 A
Charging system : Constant current, peak detection, timer controlled
Dimensions : 140 (W) x 42 (H) x 68 (D) mm (5-9/16” x 1-11/16” x 2-11/16”)
Weight : Approx. 300 g (0.71 lbs)
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject to change
without notice.
SPECIFICATIONS
