Grip Adjustment
1
Loosen the belt.
2
Pass your right hand through the loop and grasp the
grip.
3
Adjust your thumb and fingers through the grip, to
easily operate the Recording Start/Stop button and
Power Switch and Power Zoom (SHUTTLE SEARCH)
Ring. Be sure to tighten the belt to your preference.
Viewfinder Adjustment
1
Set the Power Switch to “ ” or “ ” while pressing
down the Lock Button located on the switch.
2
Pull out the viewfinder fully.
3
Turn the Diopter Adjustment Control until the
indications in the viewfinder are clearly focused.
Diopter Adjustment
Control
Power
Switch
GETTING STARTED
(cont.)
CAUTION:
When attaching the camera to a tripod, extend its
legs to stabilize the camcorder. It is not advised to use
small sized tripods. This may cause damage to the
unit by falling over.
Tripod Mounting
1
Align the screw on the tripod with the camera’s
mounting socket. Then tighten the screw.
•Some tripods are not equipped with studs.
Lock Button
