EN75
Video unit equipped with a
DV connector
Connection To A Video Unit Equipped With
A DV Connector
Connection to the GV-DT3 Digital Printer (optional)
allows you to print out images or transfer them to a PC. It
is also possible to copy recorded scenes from the
camcorder onto another video unit equipped with a DV
connector. This function is called Digital Dubbing
( pg. 59), which offers virtually no image or sound
deterioration.
1
Make sure all units are turned off.
2
Make connections to the device you want to
connect to using a DV cable, as shown in the
illustration.
3
If necessary, connect the PC connection cable
(provided with GV-DT3) to the printer’s PC
connector and the PC’s RS-232C connector.
4
Turn the camcorder’s Power Switch to “ ” while
pressing down the Lock Button located on the
switch and turn on the other units.
NOTES:
●
It is recommended to use the AC Power Adapter/
Charger as the power supply instead of the battery
pack (
pg. 11).
●
If Still Playback, Slow-Motion Playback, Fast-Forward
or Rewind is attempted with the camcorder connected
to a video unit via the DV connector, the image will
take on an effect similar to a coloured mosaic pattern
or it will become black.
●
Also refer to the instruction manuals of the connected
units.
●
When using a DV cable, be sure to use the optional
JVC VC-VDV204U DV cable.
●
When using a cable supplied with a core filter, be sure
to connect the end with the core filter to the
camcorder. The core filter reduces interference.
To DV IN/OUT
To DV
connector
Digital Printer
To DV IN
connector
PC
DV cable
(optional)
To PC
connector
PC connection
cable
To RS-232C
Open the connector
cover.
Core filter
Core filter
To Next Page
