JVC GR-DVP3

EN99
For Connectors
AV
Video output :1 V ( p-p ) , 75 Ω, analog
Audio output : 300 mV (rms), 1 kΩ, analog, stereo
DV
Input/output : 4-pin, IEEE 1394 compliant
AC Power Adapter/Charger AA-V100U
Power requirement
U.S.A. and Canada : AC 120 V`, 60 Hz
Other countries : AC 110 V to 240 V`, 50 Hz/60 Hz
Power consumption : 23 W
Output
Charge : DC 7.2 V , 1.2 A
VTR : DC 6.3 V , 1.8 A
Dimensions (W x H x D) : 68 mm x 44 mm x 110 mm (2-11/16" x 1-3/4" x 4-3/8")
Weight : Approx. 255 g (0.57 lbs)
Docking Station CU-V507U
For General
Dimensions (W x H x D) : 48.4 mm x 36 mm x 79 mm (1-15/16" x 1-7/16" x 3-1/8")
Weight : Approx. 53 g (0.12 lbs)
For Connectors
PHONE
Headphone output : ø3.5 mm, stereo
USB : TYPE B
S-VIDEO OUT : Y: 1 V (p-p), 75 Ω, analog output
C: 0.29 V (p-p), 75 Ω, analog output
EDIT : ø3.5 mm, 2-pole
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject
to change without notice.
