AUX
INPUT
2
INPUT
1
DEVICE
AV
A
BATT.RELEASE
POW
ER
/CHG
B
HDMI
REMOTE
DC
SD/HD
SDI
REC
HOST
AV
DEVICE
DC
REMOTE
HOST
Audio (Lch)
Audio (Rch)
Video
GND
SDI IN
HDMI
AV input
* Select the output signal in [A/V Set] B
[HDMI/SDI
Out].
(A P112 [ HDMI/SDI Out ] )
*
When [Record Format]
B
[System] is set to “SD”,
only SD-SDI signals are output.
(A P117 [ System ] )
* To display the menu screen or display screen on
an external monitor, set [A/V Set] B [Video Set] B
[Display On TV] to “On”.
(A P112 [ Display On TV ] )
Connecting via SDI
0
Digital video signals, together with embedded
(superimposed) audio signals and time code
signals, are
output for both the HD-SDI and SD-
SDI signals.
0
User’s bit output from the [HD/SD SDI] output
terminal is used as a flag to determine valid
video signals. Therefore, accurate values will
not be output.
Memo :
0
The sampling frequency for embedded
(superimposed) audio signals is 48 kHz. Time
code of the built-in time generator as well as
playback time code are also output.
Setting the Aspect
0
For setting the mode to convert images with a
16:9 aspect
ratio to display on a 4:3 aspect ratio
screen.
0
Set using [A/V Set] B [Video Set] B [SD
Aspect].
0
The
available
modes include “Side Cut”, “Letter”
(blackened at the top and bottom), and
“Squeeze” (full size, compressed at the left and
right).
(A P119
[ SD Aspect ] )
Memo :
0
When [Record Format]
B
[System] is set to “SD”,
and [SD Aspect] is set to “4:3”, this item cannot be
selected.
(A P117 [ System ] )
(A P119 [ SD Aspect ] )
147
Connecting External Devices
