Accessories

Warranty Card (U model only) 1

INSTRUCTIONS (BASIC) 1

AC Adapter 1

Power Cord (U model: 1, E model: 2)

Battery 1

Large Eyecup 1

Dimensional Outline Drawing (Unit: mm)

269.5

345.5

402.5

415.5

178

197

140

156.5

177.5

148.5

(HOOD)
