JVC GY-HM750U User Manual

4
Introduction
I TALLYLamp
Displaysthemonitorstatusoftheinputscreeninred.
ThelamplightsupinredonlywhenTallyPGM(Program)
signalsareinput.
Memo
 Use[TALLY]switchKtoturnON/OFFthedisplayfunction
ofthislamp.
J VFCABLEHOLDER
ForclampingtheprovidedVFcablewhenconnectingittothe
inputterminal.
Memo
 WhenconnectingtheVFcable,securethecablewiththe
holdertopreventitfromdisconnecting.(A Page 5)
K [TALLY]Switch
ForturningON/OFFtheTALLYlampI.
ON :TALLYisenabled.
OFF :TALLYisdisabled.
Memo
 ThisswitchdoesnotaffecttheoperationoftheTALLY
lampsHonthescreen.
L DIPSwitch
Donottouchastheswitchfunctioniscurrentlynotavailable.
M [VFCABLE]InputTerminal
ForconnectingtotheVFoutputterminal(20-pin)ofthe
GY-HM790seriesusingtheprovidedVFcable.
N [SDIINPUT]Terminal
TheinputterminalforSDIvideosignals.
Todisplaytheimagefromthisterminal,set[INPUTSOURCE]
inthe[VIDEOFORMAT]menuto�SDIB.(A Page 11)
Tousetheimagefromthisterminalasreturnsignals,set
[SDIRETURN]to�ONBwhile[INPUTSOURCE]isbeingset
to�VFB.
Memo
 Youcanselectthedesiredvideoformatusing
[FRAMERATE]and[FORMAT]inthe[VIDEOFORMAT]
menu.(A Page 11)
O [DCINPUT]Terminal(XLRtype,4-pin)
Thisviewfindercanbeoperatedbyconnectingtoanexternal
powersupplyofDC12V.(Whenthisviewfinderisconnected
totheGY-HM790series,itisnotnecessarytoconnectan
externalpowersupplytothisterminal.)
NamesofPartsand
Functions(Rear)
DCINPUT SDIINPUT
VFCABLE TALLY
ON
OFF
K
M
N
O
J
�
L
