5
Setup
MountingonKA-790G
1 Rotatethelockleverinthearrowdirection( )
asshowninthediagrambelow.
2 Alignthebracketforviewfindermountontopof
KA-790Gwiththegrooveattheviewfindermount
baseandinsertfromthebackofthecamerahead.
3 Rotatetheviewfinderlockleverinthearrow
direction( )asshownbelowandsecurethe
viewfindertoKA-790G.
RemovingtheViewfinder
1 WhilepressingtheReleasebutton,slidethe
viewfindertowardthebackofthecameraheadand
remove.
ConnectingVFCable
BeforeconnectingtheVFcable,besuretoturnoffthe
POWERswitchonthecameraorontheremotecontrolunit.
Connecttheviewfinder’s[VFCABLE]terminaltothe[VF]
terminaloftheGY-HM790serieswiththeprovidedVFcable.
Note
 Besuretousethecableprovidedwiththisviewfinder.
ThecableprovidedwithVF-HP840Ucannotbeused.
1 InserttheprovidedVFcablefullytothe[VF
CABLE]terminal.
2 Loosenthesetscrewonthecableholder,tiltthe
holderatanangleandinserttheVFcablefromthe
bottomintothegrooveontheholder.
3 Pressthecableholdersquarelyagainstthe
viewfinderandsecurethesetscrew.
Ifthecableholderisslanted,thesetscrewcannotbesecured
anditmaydamagethescrewholeontheviewfinder.
Note
 Besuretoturnofftheviewfinderandthecamerabefore
connectingordisconnectingthecable.
Installation
1
2
3
MountBase
BracketforViewfinderMount
LockLever
1
2
Push
ReleaseButton
LockLever
VFCable
CableHolder
SetScrew
VFCable
(Good)
(Nogood)
