SPECIFICATIONS
GENERAL
Power requirement : AC 120 V , 60 Hz
Power consumption
Power on : 25 W
Power off : 2.0 W
Temperature
Operating : 5°C to 40°C (41°F to 104°F)
Storage : –20°C to 60°C (–4°F to140°F)
Operating position : Horizontal only
Dimensions (WxHxD)
: 435 mm x 93 mm x 272 mm
(17-
3
/16” x 3-
11
/16” x 10-
3
/4”)
Weight : 4.1 kg (9.1 lbs)
Format : VHS NTSC standard
Maximum recording time
(SP) : 210 min. with T-210 video cassette
(EP) : 630 min. with T-210 video cassette
VIDEO/AUDIO (VCR deck)
Signal system : NTSC color signal and EIA
monochrome signal, 525 lines/60
fields
Recording system : DA4 (Double Azimuth) head helical
scan system
Signal-to-noise ratio: 45 dB
Horizontal resolution
: 230 lines
Frequency range : 70 Hz to 10,000 Hz (Normal audio)
20 Hz to 20,000 Hz (Hi-Fi audio)
Input/Output : RCA connectors:
IN x 1, OUT x 1
VIDEO/AUDIO (DVD deck)
Signal system : NTSC
Applicable disc : DVD (12 cm, 8 cm)
CD (12 cm, 8 cm)
Audio characteristics
DVD : 4 Hz – 22 KHz
Frequency response
CD : 4 Hz – 20 KHz
S/N Ratio : 90 dB
Harmonic distortion
: 0.1 %
Wow and flutter : Below Measurable Level
Dynamic range : 90 dB
Output
Component-Y : (RCA) 1.0 Vp-p/75 ohm
Component-P
B
/P
R
: (RCA) 0.7 Vp-p/75 ohm
Audio : (RCA) 2 Vrms, 1 Kohm
Digital Audio : (COAXIAL) 0.5 Vp-p/75 ohm
TUNER
Tuning system : Frequency synthesized tuner
Channel coverage
VHF : Channels 2 – 13
UHF : Channels 14 – 69
CATV : 113 Channels
RF output : Channel 3 or 4 (switchable; preset
to Channel 3 when shipped)
75 ohms, unbalanced
TIMER
Clock reference : Quartz
Program capacity : 1-year programmable timer/
8programs
ACCESSORIES
Provided accessories
: RF cable,
Infrared remote control unit,
“AA” battery x 2
Specifications shown are for SP mode unless otherwise
specified.
E.& O.E. Design and specifications subject to change without
notice.
