L-2 Select and L-2 Input Setting
(L-2 SELECT and L-2 INPUT)
Set “L-2 SELECT” to the appropriate mode depending on the
type of appliance connected to the unit’s L-2 IN/DECODER
connector. Set “L-2 INPUT” to the appropriate mode depending
on the output signals of the connected appliance.
A
Select the input mode for the L-2 IN/
DECODER connector.
B
Return to the normal screen.
Press
SET UP MENU
.
NOTES:
●
If you have a satellite receiver or a decoder connected to the
L-2 IN/DECODER connector, be sure to set “L-2 SELECT” back
to appropriate mode after editing.
●
If you are not connecting a satellite receiver or a decoder to
the L-2 IN/DECODER connector, leave “L-2 SELECT” set to
“A/V”.
●
The default setting is “A/V”; if the unit’s memory backup has
expired due to a power cut or because the AC was removed
from the unit, “A/V” will be automatically selected when the
power is restored to the unit. If you are using a satellite
receiver or a decoder, be sure to set “L-2 SELECT” back to
appropriate mode.
●
When “L-2 SELECT” is set to “SAT”, “SAT” or “SAt” appears on
TV screen or front display panel instead of “L-2”.
●
If “L-2 SELECT” is set to “DECODER”, it is impossible to set
“L-2 INPUT” to “S-VIDEO”.
●
If “L-1 OUTPUT” is set to “S-VIDEO”, it is impossible to set
“L-2 SELECT” to “DECODER”.
Perform steps
A
and
C
of “L-1 Output Setting
(L-1 OUTPUT)” on page 60.
Press
rt
to move the
highlight bar (pointer) to “L-2
SELECT” or “L-2 INPUT”.
Then, press
OK
or
e
to select
the appropriate setting.
* The default setting is
bold
in
the table below.
8
L-2 SELECT
A/V
: To use this unit as the recording deck
with the player connected to the L-2
IN/DECODER connector, or to use
the satellite receiver connected to the
L-2 IN/DECODER connector.
DECODER
: To use a decoder connected to the
L-2 IN/DECODER connector.
SAT
: To view a satellite programme with
the TV set while the unit is turned off.
(
墌
pg. 66)
8
L-2 INPUT
VIDEO
: If a connected appliance’s output is
compatible only with regular video
signals, set to “VIDEO”.
S-VIDEO
: If a connected appliance’s output is
compatible with Y/C signals, set to
“S-VIDEO”. You can obtain high-
quality S-VHS picture. (For
connection, be sure to use a 21-pin
SCART cable that is compatible with
the Y/C signal.)
