JVC JR-S300 Service Manual

1. Specifications
Dimensions
Weight
Amplifier Section
RMS Power
Both channels driven
(20Hz—20kHz Power Bandwidth)
RMS Power
Both channels driven at 1kHz
Total Harmonic Distortion
Damping Factor
Input Sensitivity, Impedance
Recording Output Level
Frequency Response
S.E.A. Center Frequency
S.E.A. Control Range
Crosstalk
FM Tuner Section
Usable Sensitivity
Total Harmonic Distortion
at 1kHz, 100% Modulation
Signal to Noise Ratio
Selectivity
Capture Ratio
Image Rejection
IF Rejection
Stereo Separation
AM Tuner Section
Usable Sensitivity
Selectivity
Image Rejection
IF Rejection
Signal to Noise Ratio
6-5/16"(H) x 19-11/16’'(W) x 13-3/16’(D)
(16cm x 50cm x 33.5cm)
22.9 Ibs. (10.4 kg)
50W per channel at 822
55W per channel at 8Q
65W per channel at 42
0.3% at rated output power
50 at 822
Phono: 2.5mV/50kQ
AUX: 180mV/70kQ
Tape Mon: 180mV/70kQ2
150mV (Pin)
30mV/80kQ (DIN)
20Hz —- 20kHz +0
-0.8dB
40Hz, 250Hz, 1kHz, 5kHz & 15kHz
+12dB
50dB at 1kHz
1.9uV IHF
0.2% (Mono)
0.4% (Stereo)
70dB (Mono)
60dB (Stereo)
60dB IHF Alternate
1.2dB
70dB at 88MHz
85dB at 98MHz
45dB at 1kHz
30dB at 10kHz
30nV/m, 300nV/m
30dB
45dB
50dB
55dB
JR-S300
No. 2363
