Connecting external devices
You can connect many different devices to the rear panel of the TV.
Please read the user manuals of each device before setting up.
(Connecting cables are not supplied with this TV.)
Amplifier
(L) (R)
OUT
Set-top box / Digital
broadcast tuner
Game consoles
“Technical information” (P. 35)
VCR / DVD recorder
PC IN
PC
Video camera
VIDEO-1
VIDEO-2
VIDEO-3
: signal direction
Connect a “DVI” device to
“HDMI” (P. 36)
To “VIDEO-3” R/L
Headphones
(R)
Headphone
VIDEO-1
Watching videos
Output Input
·
Composite signal /
Component signal
/ S-VIDEO
· Sound L / R
Use Component signal
“Switch between video and
component signal” (P. 22)
Use S-VIDEO
“Using S-VIDEO” (P. 22)
VIDEO-2
Watching videos
Output Input
·
Composite signal /
S-VIDEO
· Sound L / R
Use S-VIDEO
“Using S-VIDEO” (P. 22)
VIDEO-3
Watching DVDs
Output Input
·
Composite signal /
Component signal
· Sound L / R
Use Component signal
“Switch between video and
component signal” (P. 22)
HDMI
Connecting
HDMI devices
Output Input
· HDMI signal
(P. 36)
“HDMI Setting” (P. 28)
OUT
Video and sound signal of a TV channel
you are viewing outputs from this
terminal
Output
·
Composite signal /
S-VIDEO
· Sound L / R
“Using OUT terminal”. (P. 22)
VCR / DVD / other devices
(L)
(Y)
(Pb)
(Pr)
(R)
(R)
(L)
(L)
HDMI
DVD player
(HDMI compatible)
VCR / DVD recorder
IN HDMI
IN HDMI
(Y)
(Pb)
(Pr)
(R) (L)
(R)
(L)
To Next Page
