JVC LT-Z37EX6 - Sw P.w. Board Assy (Sfl-7211 A-H2); Led P.w. Board Assy (Sfl-8906 A-H2); Main Power P.w. Board Assy (Sfl-9067 A-H2)

(No.YA462)3-11
SW P.W. BOARD ASS'Y (SFL-7211A-H2)
LED P.W. BOARD ASS'Y (SFL-8906A-H2)
MAIN POWER P.W. BOARD ASS'Y (SFL-9067A-H2)
C6686 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6687 QETN1EM-477Z E CAPACITOR 470uF 25V M
R6201 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R6202 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R6203 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R6204 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R6205 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R6501 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R6502 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R6503 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6504 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R6505 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6506 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6507 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R6601 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6602 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R6603 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R6605 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R6606 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R6607 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R6621 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R6622 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6623 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R6624 QRJ146J-102X UNF C RESISTOR 1k
Ω 1/4W J
R6625 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6626 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R6627 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6629 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6630 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R6631 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6632 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R6633 NRSA63J-151X MG RESISTOR 150
Ω 1/16W J
R6634 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6661 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6662 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6663 NRSA63J-393X MG RESISTOR 39k Ω 1/16W J
R6664 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R6665 NRSA63J-393X MG RESISTOR 39k Ω 1/16W J
R6666 QRK126J-5R6X UNF C RESISTOR 5.6 Ω 1/2W J
R6667 QRK126J-220X UNF C RESISTOR 22 Ω 1/2W J
R6668 QRK126J-5R6X UNF C RESISTOR 5.6 Ω 1/2W J
R6669 QRK126J-220X UNF C RESISTOR 22 Ω 1/2W J
R6670 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R6671 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6673 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R6674 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R6675 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R6676 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6677 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6680 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6691 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
L6661 NQLC8CM-560X COIL 56uH M
L6662 NQLC8CM-560X COIL 56uH M
K6601 NQR0499-002X FERRITE BEADS
K6602 NQR0499-002X FERRITE BEADS
K6661 NQR0499-002X FERRITE BEADS
K6662 NQR0499-002X FERRITE BEADS
K6663 NQR0499-002X FERRITE BEADS
K6664 NQR0499-002X FERRITE BEADS
TH6401 NAD0035-471X P THERMISTOR 470
Ω
 Ref No. Part No. Part Name Description Local
D7011 UDZW6.2B-X Z DIODE
C7011 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7012 NCB31HK-104X C CAPACITOR 0.1uF 50V K
R7011 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7012 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7013 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7014 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R7015 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7016 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R7017 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7701 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R7702 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R7703 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R7704 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R7707 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7708 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7710 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
 Ref No. Part No. Part Name Description Local
R7711 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L7001 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L7002 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
J7001 QNS0051-001 3.5 JACK HEADPHONE
K7001 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
S7701 QSW0619-003Z PUSH SWITCH CH-
S7702 QSW0619-003Z PUSH SWITCH CH+
S7703 QSW0619-003Z PUSH SWITCH MENU/OK
S7704 QSW0619-003Z PUSH SWITCH TV/AV
S7705 QSW0619-003Z PUSH SWITCH VOL+
S7706 QSW0619-003Z PUSH SWITCH VOL-
S7707 QSW0619-003Z PUSH SWITCH POWER
 Ref No. Part No. Part Name Description Local
IC8952 GP1UM261RKVF IR DETECT UNIT
Q8905 RT1P440C-X DIGI TRANSISTOR
Q8909 RT1N241C-X DIGI TRANSISTOR
D8904 SEL5E20C-T LED POWER
D8910 MA8068-X Z DIODE
D8911 MA8068-X Z DIODE
C8952 NEHL1CM-476X E CAPACITOR 47uF 16V M
R8914 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R8917 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R8923 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R8924 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R8955 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
 Ref No. Part No. Part Name Description Local
IC9201 MIP2C20MSSCF IC
IC9501 F9222L-F219 IC
 IC9502 FA5500AN-W IC
 IC9551 UTCTL431-T IC
Q9001 2SC3928A/QR/-X TRANSISTOR
Q9002 2SC3928A/QR/-X TRANSISTOR
Q9501 2SK3522-01-F1 POWER MOS FET
Q9502 2SC3928A/QR/-X TRANSISTOR
Q9503 2SC3928A/QR/-X TRANSISTOR
Q9504 UN2213-X DIGI TRANSISTOR
Q9505 UN2212-X DIGI TRANSISTOR
Q9506 UN2212-X DIGI TRANSISTOR
Q9507 2SB1188/QR/-W TRANSISTOR
Q9508 UN2212-X DIGI TRANSISTOR
Q9531 2SC3928A/QR/-X TRANSISTOR
Q9532 2SB1188/QR/-W TRANSISTOR
Q9533 UN2212-X DIGI TRANSISTOR
Q9534 UN2213-X DIGI TRANSISTOR
Q9535 UN2213-X DIGI TRANSISTOR
Q9536 2SA1530A/QR/-X TRANSISTOR
Q9537 2SA1530A/QR/-X TRANSISTOR
Q9551 UN2212-X DIGI TRANSISTOR
Q9552 UN2212-X DIGI TRANSISTOR
Q9553 2SC3928A/QR/-X TRANSISTOR
 D9001 D25XB60 BRIDGE DIODE
D9002 1SS355W-X DIODE
D9002 MA111-X SI DIODE
D9003 1SS355W-X DIODE
D9003 MA111-X SI DIODE
D9203 EG01C-T2 SI DIODE
D9204 SSPX-66-W DIODE
D9205 UTCTL431-T IC
D9206 EC21QS10-X SB DIODE
D9208 SSPX-66-W DIODE
D9212 EM1A-LFF4 SI DIODE
D9213 EM1A-LFF4 SI DIODE
D9214 EM1A-LFF4 SI DIODE
D9215 MA8330/M/-X Z DIODE
D9216 MA8330/M/-X Z DIODE
D9501 YG972S6R SI DIODE
D9502 D1FL20U-X SI DIODE
D9503 1SS355W-X DIODE
 Ref No. Part No. Part Name Description Local
