JVC LT-Z37EX6 - Printed Wiring Board Parts List [Lt-Z37 Ex6]; Analog P.w. Board Assy (Sfl-1233 A-H2)

(No.YA462)3-7
PRINTED WIRING BOARD PARTS LIST [LT-Z37EX6]
ANALOG P.W. BOARD ASS'Y (SFL-1233A-H2)
 Ref No. Part No. Part Name Description Local
IC101 R2S11004FT IC
IC102 R2S11003FT IC
IC103 MM1510XN-X IC
IC104 MM1510XN-X IC
IC105 MM1510XN-X IC
IC106 CD4066BNS-X IC
IC381 M62320FP-X IC
IC541 SN74LC1G3157K-X IC
IC601 NJW1182FP1 IC
IC606 M62320FP-X IC
IC751 BH3547F-X IC
IC902 BA33BC0FP-X IC
IC3501 MSP3415GQGB8V3M IC
IC3503 HA17558AF-X IC
IC3504 BA80BC0FP-X IC
Q101 UN2213-X DIGI TRANSISTOR
Q102 UN2213-X DIGI TRANSISTOR
Q106 2SK1374-X MOS FET
Q107 2SK1374-X MOS FET
Q108 2SC3928A/QR/-X TRANSISTOR
Q109 2SA1022/BC/-X TRANSISTOR
Q110 2SA1022/BC/-X TRANSISTOR
Q111 2SA1022/BC/-X TRANSISTOR
Q112 2SA1022/BC/-X TRANSISTOR
Q113 2SC3928A/QR/-X TRANSISTOR
Q281 2SA1530A/QR/-X TRANSISTOR
Q431 UN2226-X DIGI TRANSISTOR
Q432 UN2226-X DIGI TRANSISTOR
Q433 UN2110-X DIGI TRANSISTOR
Q609 2SC3928A/QR/-X TRANSISTOR
Q614 2SA1530A/QR/-X TRANSISTOR
Q621 2SA1530A/QR/-X TRANSISTOR
Q622 2SC3928A/QR/-X TRANSISTOR
Q751 2SA1530A/QR/-X TRANSISTOR
Q752 UN2226-X DIGI TRANSISTOR
Q3001 2SC3928A/QR/-X TRANSISTOR
Q3502 2SC3928A/QR/-X TRANSISTOR
Q3503 UN2213-X DIGI TRANSISTOR
D105 MA111-X SI DIODE
D281 1SS355-X SI DIODE
D282 1SS355-X SI DIODE
D283 1SS355-X SI DIODE
D401 UDZS10B-X Z DIODE
D402 UDZS10B-X Z DIODE
D403 UDZS10B-X Z DIODE
D404 UDZS10B-X Z DIODE
D405 UDZS10B-X Z DIODE
D406 UDZS10B-X Z DIODE
D407 UDZS10B-X Z DIODE
D408 UDZS10B-X Z DIODE
D409 UDZS10B-X Z DIODE
D411 UDZS10B-X Z DIODE
D412 UDZS10B-X Z DIODE
D413 UDZS10B-X Z DIODE
D414 UDZS10B-X Z DIODE
D415 UDZS10B-X Z DIODE
D416 UDZS10B-X Z DIODE
D420 UDZS10B-X Z DIODE
D421 UDZS10B-X Z DIODE
D422 UDZS10B-X Z DIODE
D423 UDZS10B-X Z DIODE
D424 UDZS10B-X Z DIODE
D425 UDZS10B-X Z DIODE
D427 UDZS10B-X Z DIODE
D428 UDZS10B-X Z DIODE
D431 UDZS10B-X Z DIODE
D432 UDZS10B-X Z DIODE
D461 UDZS10B-X Z DIODE
D462 UDZS10B-X Z DIODE
D463 UDZS10B-X Z DIODE
D464 UDZS10B-X Z DIODE
D465 UDZS10B-X Z DIODE
D466 UDZS10B-X Z DIODE
D491 UDZS3.3B-X Z DIODE
D492 S9648 PHOTO CONDUCTOR
D503 MA8033-X Z DIODE
D605 1SS355-X SI DIODE
D606 1SS355-X SI DIODE
D607 1SS355-X SI DIODE
D608 1SS355-X SI DIODE
D615 1SS355-X SI DIODE
D621 1SS355-X SI DIODE
D622 1SS355-X SI DIODE
D751 1SS355-X SI DIODE
D752 1SS355-X SI DIODE
C101 NEHL1CM-107X E CAPACITOR 100uF 16V M
C102 NCB11CK-225X C CAPACITOR 2.2uF 16V K
C103 NCB11CK-225X C CAPACITOR 2.2uF 16V K
C106 NCB11CK-475X C CAPACITOR 4.7uF 16V K
C107 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C108 NEHL1CM-476X E CAPACITOR 47uF 16V M
C116 NCB11AK-106X C CAPACITOR 10uF 10V K
C117 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C118 NCB31CK-105X C CAPACITOR 1uF 16V K
C119 NCB31CK-105X C CAPACITOR 1uF 16V K
C120 NCB31CK-105X C CAPACITOR 1uF 16V K
C121 NCB31CK-105X C CAPACITOR 1uF 16V K
C122 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C123 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C124 NCB31CK-105X C CAPACITOR 1uF 16V K
C125 NCB31CK-105X C CAPACITOR 1uF 16V K
C126 NCB31CK-105X C CAPACITOR 1uF 16V K
C127 NCB31CK-105X C CAPACITOR 1uF 16V K
C128 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C129 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C130 NEHL1CM-476X E CAPACITOR 47uF 16V M
C131 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C132 NCB31CK-105X C CAPACITOR 1uF 16V K
C133 NCB31CK-105X C CAPACITOR 1uF 16V K
C134 NCB31CK-105X C CAPACITOR 1uF 16V K
C138 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C141 NEHL1CM-106X E CAPACITOR 10uF 16V M
C142 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C143 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C144 NCB31CK-105X C CAPACITOR 1uF 16V K
C145 NEHL1CM-106X E CAPACITOR 10uF 16V M
C146 NEHL1AM-107X E CAPACITOR 100uF 10V M
C147 NEHL1CM-106X E CAPACITOR 10uF 16V M
C148 NCB31CK-105X C CAPACITOR 1uF 16V K
C149 NEHL1CM-106X E CAPACITOR 10uF 16V M
C150 NEHL1AM-107X E CAPACITOR 100uF 10V M
C151 NEHL1CM-106X E CAPACITOR 10uF 16V M
C152 NCB31CK-105X C CAPACITOR 1uF 16V K
C153 NEHL1CM-106X E CAPACITOR 10uF 16V M
C154 NEHL1AM-107X E CAPACITOR 100uF 10V M
C155 NEHL1CM-106X E CAPACITOR 10uF 16V M
C156 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C157 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C158 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C161 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C166 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C167 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C168 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C169 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C170 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C171 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C172 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C173 NDC31HJ-680X C CAPACITOR 68pF 50V J
C174 NDC31HJ-331X C CAPACITOR 330pF 50V J
C175 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C176 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C177 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C178 NCB31CK-105X C CAPACITOR 1uF 16V K
C179 NEHL1CM-476X E CAPACITOR 47uF 16V M
C180 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C181 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C182 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C183 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C184 NDC31HJ-151X C CAPACITOR 150pF 50V J
C185 NDC31HJ-820X C CAPACITOR 82pF 50V J
C187 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C189 NEHL1CM-106X E CAPACITOR 10uF 16V M
C199 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C200 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C201 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C202 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C204 NCB11CK-475X C CAPACITOR 4.7uF 16V K
C206 NCB11CK-475X C CAPACITOR 4.7uF 16V K
C211 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C233 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C234 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C235 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C261 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C262 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C263 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C264 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C265 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C266 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C267 NCB31CK-104X C CAPACITOR 0.1uF 16V K
 Ref No. Part No. Part Name Description Local
