3-4(No.YA462)
EXPLODED VIEW PARTS LIST -1
Ref.No. Part No. Part Name Description Local
101 LC12550-002B-0K JACK COVER
102 LC41424-002A HDMI WARNING
103 LC42546-001A-C STAND BASE UNIT Inc.103A
103A T0176-01 STAND COVER
104 LC42531-001A-C SUPPORT UNIT Inc.104A/104B
104A P0244-M9-03-01 SCREW (x2)
104B M04R-PPBF-C3-7 SCREW (x4)
106 QYSPSPD5014MA SCREW M5 x 14mm(x4)
108 LC12775-003A-H REAR COVER
109 QYSBSFG4016MA TAP SCREW M4 x 16mm(x10)
110 LC42446-002A SCREW (x2)
111 QYSBSF3010MA TAP SCREW M3 x 10mm(x5)
112 QUQL05-4009AA-E FFC WIRE DIGITAL CN002-ANALOG CN002
113 QUQL05-5009AA-E FFC WIRE DIGITAL CN001-ANALOG CN001
114 QJJ009-151010-E SIN CR C-C WIRE DIGITAL CNODC-DC-DC DC
115 QQR0490-001 NOISE FILTER LT-Z37EX6A,LT-Z37EX6S
116 QQR0490-001 NOISE FILTER LT-Z37EX6A,LT-Z37EX6S
117 LC42446-001A SCREW
118 LC42340-001C-H SERVICE COVER
119 LC42446-001A SCREW
120 QYSPSP3004ZA SCREW M3 x 4mm
121 LC12497-010A-H SHIELD TERMINAL
122 QJJ064-100600-E SIN CR C-C WIRE ANALOG S-D-AMP CN00S
123 WJZ0207-001A-E E-HARNESS ASSY SPEAKER
124 QJJ009-150710-E SIN CR C-C WIRE ANALOG H-DC-DC H
125 QQR0490-001 NOISE FILTER (x2) LT-Z37EX6A,LT-Z37EX6S
126 LC12507-006B-0K TUNER BASE
127 LC42446-002A SCREW (x2)
128 LC12506-002D-0K TERMINAL BASE
129 QYSBSF3010MA TAP SCREW M3 x 10mm(x3)
130 QNB0036-001 CONNECTOR ACCESSORY (x2)
131 QJJ015-043024-E SIN CR C-C WIRE MAIN POWER F-D-AMP CN10F
132 QJJ009-151010-E SIN CR C-C WIRE MAIN POWER A-DC-DC A
133 QMPK450-170-JC POWER CORD(EU) 1.7m BLACK LT-Z37EX6
133 QMPG110-170-JC POWER CORD(AST) 1.7m BLACK LT-Z37EX6A
133 QMPR990-165-K2 POWER CORD 1.65m BLACK LT-Z37EX6B
133 QMPN370-170-JC POWER CORD(EK) 1.7m BLACK LT-Z37EX6S
134 QQR0491-001 FERRITE CORE
135 LC22007-002A-0K POWER CORD HOLDER
136 LC33553-007A-H OPERATION SHEET
137 LC33555-004A-H OPERATION SHEET
138 LC33554-003A-H OPERATION SHEET
139 LC42056-001A SHADE SPACER (x2)
201 SFL0D361A-H2 DIGITAL PWB LT-Z37EX6
201 SFL0D364A-H2 DIGITAL PWB LT-Z37EX6A,LT-Z37EX6S
201 SFL0D361A-BK DIGITAL PWB LT-Z37EX6B
202 SFL-6232A-H2 D-AMP PWB LT-Z37EX6,LT-Z37EX6A,LT-Z37EX6S
202 SFL-6232A-BK D-AMP PWB LT-Z37EX6B
203 SFL-1233A-H2 ANALOG PWB LT-Z37EX6,LT-Z37EX6A,LT-Z37EX6S
203 SFL-1233A-BK ANALOG PWB LT-Z37EX6B
204 SFL-9177A-H2 DC-DC PWB LT-Z37EX6,LT-Z37EX6A,LT-Z37EX6S
204 SFL-9177A-BK DC-DC PWB LT-Z37EX6B
205 SFL-9067A-H2 MAIN POWER PWB LT-Z37EX6,LT-Z37EX6A,LT-Z37EX6S
205 SFL-9067A-BK MAIN POWER PWB LT-Z37EX6B
To Next Page
