JVC LT-Z37EX6 - D-Amp P.w. Board Assy (Sfl-6232 A-Bk)

(No.YA462)3-29
D-AMP P.W. BOARD ASS'Y (SFL-6232A-BK)
R675 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R687 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R688 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R689 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R690 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R694 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R695 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R696 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R700 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R701 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R702 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R703 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R704 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R718 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R719 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R720 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R723 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R751 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R752 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R755 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R756 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R757 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R758 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R759 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R760 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R761 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R764 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R765 NRSA63J-220X MG RESISTOR 22 Ω 1/16W J
R768 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R769 NRSA63J-220X MG RESISTOR 22 Ω 1/16W J
R3006 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3007 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3008 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3009 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R3010 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3011 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3014 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3015 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3016 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3504 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3505 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3506 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3508 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3511 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R3512 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3514 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3515 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3516 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3517 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3518 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3519 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3520 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3521 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3546 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R3547 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R3551 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R3552 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R3553 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R3554 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R3555 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R3556 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R3557 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3558 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3559 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R3560 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R3561 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R3562 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R3563 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3564 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
L101 NQL79GM-100X COIL 10uH M
L902 NQL52EM-220X COIL 22uH M
L903 NQR0562-010X CHOKE COIL
L906 NQL52EM-220X COIL 22uH M
L3002 NQL79GM-100X COIL 10uH M
L3003 NQL79GM-220X COIL 22uH M
L3502 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L3503 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L3504 NQL79GM-4R7X COIL 4.7uH M
L3506 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L3507 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L3508 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
CN001 QGF0508C2-50W CONNECTOR FFC/FPC (1-50)
CN002 QGF0508C2-40W CONNECTOR FFC/FPC (1-40)
J401 QNZ0726-001 AV JACK VIDEO-1(S/V/L/R)
J402 QNN0650-001 PIN JACK
VIDEO-1(COMPONENT)
J403 QNZ0726-001 AV JACK VIDEO-2(S/V/L/R)
J405 QNN0651-001 PIN JACK VIDEO-3(V/L/R)
 Ref No. Part No. Part Name Description Local
J406 QNN0650-001 PIN JACK
VIDEO-
3(COMPONENT)
J407 QNN0652-001 PIN JACK IN(HDMI-1)
J408 QNZ0726-001 AV JACK OUT(S/V/L/R)
J410 QNZ0561-001 D CONNECTOR PC IN
K662 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K663 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K3501 NQR0389-003X FERRITE BEADS
K3502 NQR0389-003X FERRITE BEADS
LC3501 NQR0431-001X EMI FILTER 0.22uF 50V Z
TU3001 QAU0390-001 TUNER
X3501 QAX0773-001Z CRYSTAL 18.432000MHz
 Ref No. Part No. Part Name Description Local
IC6201 PQ20WZ11-X IC
IC6501 RC4558D-X IC
IC6621 LM393DR-X IC
IC6661 TDA8928ST/N1 IC
Q6661 UN2112-X DIGI TRANSISTOR
Q6662 2SC3928A/QR/-X TRANSISTOR
Q6663 UN2212-X DIGI TRANSISTOR
D6201 1SS355W-X DIODE
D6501 UDZW6.2B-X Z DIODE
D6663 UDZW3.3B-X Z DIODE
D6664 1SS355W-X DIODE
D6671 UDZW20B-X Z DIODE
D6672 UDZW20B-X Z DIODE
D6673 UDZW20B-X Z DIODE
D6674 UDZW20B-X Z DIODE
C6201 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C6202 NEHL1EM-336X E CAPACITOR 33uF 25V M
C6203 NEHL1EM-336X E CAPACITOR 33uF 25V M
C6204 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C6205 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C6501 NENA1CM-475X BP E CAPACITOR 4.7uF 16V M
C6502 NENA1CM-475X BP E CAPACITOR 4.7uF 16V M
C6503 NDC31HJ-100X C CAPACITOR 10pF 50V J
C6504 NDC31HJ-100X C CAPACITOR 10pF 50V J
C6505 NEHL1CM-476X E CAPACITOR 47uF 16V M
C6506 NEHL1CM-476X E CAPACITOR 47uF 16V M
C6507 NEHL1HM-105X E CAPACITOR 1uF 50V M
C6508 NEHL1HM-105X E CAPACITOR 1uF 50V M
C6601 NDC31HJ-101X C CAPACITOR 100pF 50V J
C6602 NDC31HJ-101X C CAPACITOR 100pF 50V J
C6621 NCB31HK-332X C CAPACITOR 3300pF 50V K
C6622 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6623 NEHL1EM-226X E CAPACITOR 22uF 25V M
C6624 NCB31HK-222X C CAPACITOR 2200pF 50V K
C6625 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6626 NCB31HK-222X C CAPACITOR 2200pF 50V K
C6627 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6628 NEHL1EM-226X E CAPACITOR 22uF 25V M
C6629 NCB31HK-222X C CAPACITOR 2200pF 50V K
C6630 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6631 NCB31HK-222X C CAPACITOR 2200pF 50V K
C6632 NCB31HK-332X C CAPACITOR 3300pF 50V K
C6661 NCB11EK-105X C CAPACITOR 1uF 25V K
C6662 NCB11EK-105X C CAPACITOR 1uF 25V K
C6663 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6664 QETN1HM-226Z E CAPACITOR 22uF 50V M
C6665 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6666 QETN1HM-226Z E CAPACITOR 22uF 50V M
C6667 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6668 NCB31HK-561X C CAPACITOR 560pF 50V K
C6669 QFV21HJ-224Z MF CAPACITOR 0.22uF 50V J
C6670 QFVF1HJ-474Z MF CAPACITOR 0.47uF 50V J
C6671 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C6672 QETN1EM-477Z E CAPACITOR 470uF 25V M
C6673 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6674 QETN1EM-477Z E CAPACITOR 470uF 25V M
C6675 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6676 NCB31HK-561X C CAPACITOR 560pF 50V K
C6677 NCB31HK-561X C CAPACITOR 560pF 50V K
C6678 QFV21HJ-224Z MF CAPACITOR 0.22uF 50V J
C6679 QFVF1HJ-474Z MF CAPACITOR 0.47uF 50V J
C6680 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C6681 NCB31HK-561X C CAPACITOR 560pF 50V K
C6682 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6683 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6684 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6685 QETN1EM-477Z E CAPACITOR 470uF 25V M
 Ref No. Part No. Part Name Description Local
