51
Maintenance
*Supported timing for 3D signal in Frame Sequential, Top-Bottom or Side-by-Side format.
**Supported timing for 3D signal in Frame Sequential format.
***Supported timing for 3D signal in Top-Bottom or Side-by-Side format.
****Supported timing for 3D signal in Top-Bottom format.
The timings showing above may not be supported due to EDID file and VGA graphic card limitations. It is
possible that some timings cannot be chosen.
*Supported timing for 3D signal in Frame Sequential format.
**Supported timing for 3D signal in Frame Sequential or Top-Bottom format.
***Supported timing for 3D signal in Side-by-Side format.
1440 x 900 WXGA+_60*** 59.887 55.935 106.500
1400 x 1050 SXGA+_60*** 59.978 65.317 121.750
1600 x 1200 UXGA**** 60.000 75.000 162.000
1680 x 1050 1680 x 1050_60*** 59.954 65.290 146.250
640 x 480@67Hz MAC13 66.667 35.000 30.240
832 x 624@75Hz MAC16 74.546 49.722 57.280
1024 x 768@75Hz MAC19 75.020 60.241 80.000
1152 x 870@75Hz MAC21 75.06 68.68 100.00
1920 x 1080@60Hz
1920 x 1080_60
(Reduce Blanking)
60 67.5 148.5
1920 x 1200@60Hz
1920 x 1200_60
(Reduce Blanking)
59.95 74.038 154
Timing Resolution
Vertical
Frequency (Hz)
Horizontal
Frequency (KHz)
Pixel Frequency
(MHz)
480i* 720 x 480 59.94 15.73 27
480p 720 x 480 59.94 31.47 27
576i 720 x 576 50 15.63 27
576p 720 x 576 50 31.25 27
720/50p** 1280 x 720 50 37.5 74.25
720/60p** 1280 x 720 60 45.00 74.25
1080/24P** 1920 x 1080 24 27 74.25
1080/25P 1920 x 1080 25 28.13 74.25
1080/30P 1920 x 1080 30 33.75 74.25
1080/50i*** 1920 x 1080 50 28.13 74.25
1080/60i*** 1920 x 1080 60 33.75 74.25
1080/50P*** 1920 x 1080 50 56.25 148.5
1080/60P*** 1920 x 1080 60 67.5 148.5
