JVC LX-FH50 - Supported Timing for Component-YPbPr Input; Supported Timing for S-Video;Video Input

52
Maintenance
Supported timing for Component-YPbPr input
Supported timing for S-Video/Video input
Format Resolution
Vertical Frequency
(Hz)
Horizontal
Frequency (KHz)
Pixel Frequency (MHz)
480i 720 x 480 59.94 15.73 13.5
480p 720 x 480 59.94 31.47 27
576i 720 x 576 50 15.63 13.5
576p 720 x 576 50 31.25 27
720/50p 1280 x 720 50 37.5 74.25
720/60p 1280 x 720 60 45.00 74.25
1080/50i 1920 x 1080 50 28.13 74.25
1080/60i 1920 x 1080 60 33.75 74.25
1080/24P 1920 x 1080 24
27
74.25
1080/25P 1920 x 1080 25 28.13 74.25
1080/30P 1920 x 1080 30 33.75 74.25
1080/50P 1920 x 1080 50 56.25 148.5
1080/60P 1920 x 1080 60 67.5 148.5
Format
Vertical Frequency
(Hz)
Horizontal
Frequency (KHz)
Pixel Frequency
(MHz)
NTSC 60 15.73 3.58
PAL 50 15.63 4.43
SECAM 50 15.63 4.25/4.41
PAL-M 60 15.73 3.58
PAL-N 50 15.63 3.58
PAL-60 60 15.73 4.43
NTSC4.43 60 15.73 4.43
