64
Reference
Tuner
FM frequency: 87.50 MHz – 108.00 MHz
Terminal (front of the main unit)
• USB digital input terminal x 1
• Audio output headphone terminal x 1
Impedance: 16 Ω – 1 kΩ
Terminal (rear of the main unit)
• Audio output speaker terminals x 1
Left/Right speakers :
Output power:
For CA-NXF55:
80 W (20 W x 4) at 4 Ω
(1 kHz/10% THD)
For CA-NXF40/CA-NXF30:
220 W (55 W x 4) at 3 Ω
(1 kHz/10% THD)
Impedance:
For CA-NXF55: 4 Ω – 16 Ω
For CA-NXF40/CA-NXF30: 3 Ω – 16 Ω
Subwoofer
Output power: 180 W at 6 Ω
(100 Hz/10% THD)
Impedance: 6 Ω – 16 Ω
• Optical digital input terminal x 1
–23 dBm to –15 dBm
• Optical digital output terminal x 1
–23 dBm to –15 dBm
• Component video output terminals x 1
Y: 1.0 Vp-p, 75 Ω terminated
P
B: 0.7 Vp-p, 75 Ω terminated
P
R: 0.7 Vp-p, 75 Ω terminated
• Composite video output terminal x 1
1.0 Vp-p, 75 Ω terminated
• Audio input terminals x 1
500 mV/47 kΩ
• HDMI monitor output terminal x 1
• FM antenna terminal x 1
USB
Compatible with USB 2.0 Full-Speed
Compatible device: USB mass storage class device
Compatible file system: FAT16, FAT32
Output power: DC 5 V 500 mA
HDMI
Output power: DC 5 V 55 mA
General
Power source: AC 230 V , 50 Hz
Power consumption (in operation):
For CA-NXF55: 80 W
For CA-NXF40/CA-NXF30:100 W
Power consumption (on standby):1.00 W or less
Dimensions (W x H x D) [including projecting parts]:
312 mm x 95 mm x 312.3 mm
Mass: 3.5 kg
Type: 1-way Acoustic Suspension
Type
(Magnetically shielded type)
Speaker unit: 9.5 cm x 1.0 cm Dome x 2
(per each speaker)
Power handling capacity:20 W
Impedance: 4 Ω
Frequency range: 110 Hz – 23 kHz
Sound pressure level:81.5 dB/W
•m
Dimensions (W x H x D)
:
186 mm x 300 mm x 30.8 mm
186 mm x 296 mm x 87 mm
(with stand)
Mass: 0.85 kg per each speaker
0.94 kg per each speaker
(with stand)
Type: 1-way bass reflex type
Magnetically shielded type
Speaker driver: Front ch:5.5 cm cone
Surround ch:5.5 cm cone
Power handling capacity:
Front ch:55 W
Surround ch:55 W
Impedance: 3 Ω
Frequency range: 80 Hz – 20 kHz
Sound pressure level: 77 dB/W
•m
Dimensions (W x H x D) [including projection parts]:
88 mm x 203 mm x 127 mm
Mass (1 speaker): 1.2 kg
Type: Bass reflex type
Speaker driver: 16 cm cone
Power handling capacity:180 W
Impedance: 6 Ω
Frequency range: 30 Hz – 200 Hz
Sound pressure level: 76 dB/W
•m
Dimensions (W x H x D):
300 mm x 301 mm x 303 mm
Mass: 8.2 kg
Remote control x 1
Batteries x 2
FM antenna x 1
Composite video cable x 1
Core filter (large) x 1 (for the power cord)
Core filter (small) x 1 (for the USB cable)
For SP-NXF55 only:
Speaker cables x 2 (for SP-THFT3F)
Speaker stands x 2 (for SP-THFT3F)
Screws for stand (M5 x 10 mm) x 4
(for SP-THFT3F)
Designs and specifications are subject to change
without notice.
Main unit (CA-NXF55/
CA-NXF40/CA-NXF30)
Speakers (SP-THFT3F)
(For NX-F55)
Speakers (SP-NXF40F/
SP-NXF30F)
(For NX-F40/NX-F30)
Subwoofer (SP-NXF30W)
(For NX-F55/NX-F40/NX-F30)
Supplied accessories
Specifications
NX-F40_NX-F30[B].book Page 64 Thursday, December 24, 2009 2:00 PM
