Page 47
Specifications
Amplifier
Output Power At Stereo operation 110 watts per channel, min. RMS, both
channels driven into 8 ohms, 20 Hz to 20 kHz
with no more than 0.06 % total harmonic
distortion.
At Surround operation
Front Channels 110 watts per channel, min. RMS, driven into 8 ohms at 1 kHz
with no more than 0.8 % total harmonic distortion.
Center channel 110 watts, min. RMS, driven into 8 ohms at 1 kHz, with no more
than 0.8 % total harmonic distortion.
Rear channels 110 watts, min. RMS, driven into 8 ohms at 1 kHz, with no more
than 0.8 % total harmonic distortion.
Total Harmonic Distortion 0.06 %* at 110 watts output
(8 ohms, 1 kHz) (* Measured by JVC Audio Analysis System)
Audio Input Sensitivity/ PHONO (MM) 2.5 mV/47 k ohms
Impedance (1 kHz) CD, TAPE, TV SOUND, VCR, 230 mV/47 k ohms
VIDEO
Audio Output Level TAPE, VCR 230 mV
Signal-to-Noise Ratio PHONO 70 dB/78 dB (at REC OUT)
(’66 IHF/’78 IHF) CD, TAPE, TV SOUND, VCR, 87 dB/80 dB
VIDEO
Frequency Response (8 ohms) PHONO 20 Hz to 20 kHz (±1 dB)
CD, TAPE, TV SOUND, VCR, 20 Hz to 20 kHz (±1 dB)
VIDEO
RIAA Phono Equalization ±0.5 dB (20 Hz to 20 kHz)
Loudness Control +6 ±1 dB at 100 Hz
(Volume Control at –40 dB) +4 ±1 dB at 10 kHz
S.E.A. Center Frequencies 100 Hz, 1 kHz, 10 kHz
Control Range ±10 dB ±2 dB
Video
Video Input Sensitivity/Impedance VCR, VIDEO 1 Vp-p/75 ohms
Video Output Level VCR, MONITOR OUT 1 Vp-p/75 ohms
Synchronization Negative
Signal-to-Noise Ratio 45 dB
On-Screen Color System NTSC
